ABB MOTOR PROTECTION AND CONTROL 12/20

—
Ethernet interfaces
Ordering details

Description EIU32.0
Ethernet communication interfaces enable • Protocol EtherNet/IP™
the UMC100.3 to communicate via an Ethernet • ODVA-certified
network. There are two types of interfaces: • For one motor controller UMC100.3
• Mounting directly on an UMC100.3
2CDC341003S0012 Interfaces for the connection of one to four (supplied by UMC100.3) or remotely on an
Universal Motor Controllers UMC100.3:
SMK3.0 adapter (24 V DC supply required)
• PNQ22-FBP.0 for Profinet IO
• Supports all network topologies
MTQ22-FBP.0 • MTQ22-FBP.0 for Modbus TCP • Integrated Ethernet switch
• DLR (Device Level Ring) function for
Interface for a single universal motor control- redundancy
ler UMC100.3: • Easy to use in withdrawable applications
• EIU32.0 for EtherNet/IP™ • No special Ethernet connectors required
in MCCs
MTQ22-FBP.0 • EDS download from UMC100.3 webpage
• Protocol Modbus TCP
• For one to four UMC100.3
2CDC341001S0014 • Master supervision with timeout control PNU32.0
• Protocol Profinet
for up to four masters
• PNO-certified
• Micro USB-port for configuration via PC
(configuration software downloaded from • For one motor controller UMC100.3
PNQ22-FBP.0 • Mounting directly on an UMC100.3
UMC100.3 webpage) (supplied by UMC100.3) or remotely on an
• Integrated Ethernet switch SMK3.0 adapter (24 V DC supply required)
• Supports all network topologies • Integrated Ethernet switch
• Ring topology with redundancy • Supports all network topologies
(MRP protocol) • MRP redundancy
• Easy to use in withdrawable applications • S2 master redundancy supported
• No special Ethernet connectors required • Easy to use in withdrawable applications
in MCCs • No special Ethernet connectors required
2CDC341009V0018 • DIN-rail mounting • GSDML download from UMC100.3
• 24 V DC supply voltage
in MCCs
PNQ22-FBP.0 webpage
EIU32.0 • Protocol Profinet IO
• PNO-certified
• For one to four UMC100.3 devices
• Integrated Ethernet switch
• Supports all network topologies
• Ring topology with redundancy 12
(MRP protocol)
• Easy to use in withdrawable applications
• No special Ethernet connectors required
2CDC341003V0021 • Fully integrated into ABB 800xA
in MCCs

• 24 V DC supply voltage
PNU32.0 • Time-stamped events with ABB 800xA
• DIN-rail mounting
• GSDML downloaded from UMC100.3
webpage

Description Type Order code Pkg Weight
qty (1 pc.) kg
Ethernet Modbus TCP interface MTQ22-FBP.0 1SAJ260000R0100 1 0.172
Ethernet Profinet IO interface PNQ22-FBP.0 1SAJ261000R0100 1 0.172
EtherNet/IP TM interface EIU32.0 1SAJ262000R0100 1 0.110
Ethernet Profinet S2 interface PNU32.0 1SAJ263000R0100 1 0.110
