Add-on auxiliary contacts
Terminal marking and positioning
Connection with ring tongue ferrules

2-pole auxiliary contacts

13X / 44X 21X / 32X 31X / 22X 43X / 14X 21 33 13 21
NO NC NC NO NC NO NO NC
14X / 43X 22X / 31X 32X / 21X 44X / 13X 22 34 14 22
CAL4-11RT CAL4-11RT CAT4-11MRT CAT4-11ERT
(Left-side mounted) (Right-side mounted) CA4-11MRT CA4-11ERT

13X / 44X 21X / 32X 31X / 22X 43X / 14X 53X / 84X 61X / 72X 71X / 62X 83X / 54X
E0467D3F E0468D3F E2168D2F E2169D2F
NO NC NC NO NO NC NC NO
14X / 43X 22X / 31X 32X / 21X 44X / 13X 54X / 83X 62X / 71X 72X / 61X 84X / 53X
04
CAL18-11-RT, CAL19-11-RT CAL18-11-RT, CAL19-11-RT CAL19-11B-RT CAL19-11B-RT
(Left-side mounted) (Right-side mounted) (Left-side mounted) (Right-side mounted)

4-pole auxiliary contacts

13 23 33 43 21 33 43 53 53 63 73 83 3 1 1 3
NO NO NO NO NC NO NO NO NO NO NO NO NO NC NC NO
14 24 34 44 22 34 44 54 54 64 74 84 4 2 2 4
CA4-40ERT CA4-31MRT CA4-40NRT CA4-22URT

13 21 33 43 21 31 43 53 53 61 73 83
NO NC NO NO NC NC NO NO NO NC NO NO
14 22 34 44 22 32 44 54 54 62 74 84
CA4-31ERT CA4-22MRT CA4-31NRT

13 21 31 43 53 61 71 83
NO NC NC NO NO NC NC NO
14 22 32 44 54 62 72 84
CA4-22ERT CA4-22NRT

13 21 31 43
NO NC NC NO
E2318D2
14 22 32 44
CA5-22 ERT

13 21 33 43
NO NC NO NO
E2319D2
14 22 34 44
CA5-31ERT

13 23 33 43
NO NO NO NO
E2317D2
14 24 34 44 1SBC101846S0201 - Rev. C
CA5-40ERT
