ABB MOTOR CONTROL AND PROTECTION FOR ROLLING STOCK APPLICATIONS 4/103
—
AF190B..RT, AF205B..RT 3-pole contactors
210 8.27" 152 5.98"
196 7.727"
04
AF190B, AF205B-30-22RT
+ VM19 mechanical interlocking unit
6 X
35 1.38" 70 2.76" 35 1.38" M5 10-24 UNC
165 6.50"
AF190B, AF205B-30-22RT
+ VM19 mechanical interlocking unit
1SFC101243C0201
Main dimensions mm, inches
