ABB MOTOR CONTROL AND PROTECTION FOR ROLLING STOCK APPLICATIONS 2/25

—
Accessories

MS132-(K)B, MO132-B

02
Three-phase busbars ensure a quick and safe connection and are therefore a cost effective
2CDC241017F0010 solution. A variety of different three-phase busbars up to 100 A are in the assortment. Between
2 and 4 manual motor starters with none, one or two lateral auxiliary contacts can be connected.
Different three-phase feeder terminals are available according to the application.
Phase connecting links and phase power infeed blocks are also available for single-phase
applications.
PS1-2-0-65
Suitable for Rated Number Number Type Order code Pkg Weight
operational of manual of lateral qty (1 pce)
2CDC241014F0010 A starters contacts kg
motor
current
auxiliary
Three-phase busbars
MS132-B, 65 2 0 PS1-2-0-65 1SAM201906R1102 10 0.034
PS1-3-1-100 MO132-B 65 3 0 PS1-3-0-65 1SAM201906R1103 10 0.055
65 4 0 PS1-4-0-65 1SAM201906R1104 10 0.077
65 5 0 PS1-5-0-65 1SAM201906R1105 10 0.098
65 2 1 PS1-2-1-65 1SAM201906R1112 10 0.036
1SBC101226F0014 65 3 4 1 1 PS1-3-1-65 1SAM201906R1113 10 0.060
10
65
0.087
1SAM201906R1114
PS1-4-1-65
65
1SAM201906R1122
0.040
PS1-2-2-65
65 5 2 1 2 PS1-5-1-65 1SAM201906R1115 10 0.108
10
65 3 2 PS1-3-2-65 1SAM201906R1123 10 0.067
S1-M1-25
65 4 2 PS1-4-2-65 1SAM201906R1124 10 0.095
65 5 2 PS1-5-2-65 1SAM201906R1125 10 0.122
MS132-B, 100 3 0 PS1-3-0-100 1SAM201916R1103 10 0.084
MO132-B 100 4 0 PS1-4-0-100 1SAM201916R1104 10 0.117
1SBC101266F0014 100 5 3 0 1 PS1-5-0-100 1SAM201916R1105 10 0.154
0.094
100
PS1-3-1-100
10
1SAM201916R1113
100
10
0.172
1SAM201916R1115
PS1-5-1-100
100 4 5 1 1 PS1-4-1-100 1SAM201916R1114 10 0.134
S1-M2-25 100 3 2 PS1-3-2-100 1SAM201916R1123 10 0.105
Note: busbars are only suitable for screw versions
2CDC241023F0013 Suitable for Rated Rated cross Mounting Type Order code Pkg Weight
operational
form
section
(1 pce)
qty
A current mm² kg
SA2
Three-phase feeder terminals
MS132-B, 65 25 Flat S1-M1-25 1SAM201907R1101 10 0.038
MO132-B 65 25 High S1-M2-25 1SAM201907R1102 10 0.051
65 25 UL/CSA Type S1-M3-25 1SAM201907R1103 10 0.042
E/F and IEC
100 35 UL/CSA Type S1-M3-35 1SAM201913R1103 10 0.060
SK0108B91 E/F and IEC
PB1-1-32
Suitable for Description Type Order code Pkg Weight
qty (1 pce)
kg
2CDC241004F0014 MS132-B, MO132-B Protection cover for busbars BS1-3 1SAM201908R1001 50 0.003
1SAM201909R1001
1
Screw fixing kit
FS116
0.020
MS132-(K)B, MO132-B,
0.020
SA2
GJF1101903R0002
10
Padlock + two keys
Accessories for single-phase connection (IEC only)
S1-PB1-25
MS132-B, MO132-B Phase connecting link PB1-1-32 1SAM201914R1001 1 0.009
Phase power infeed block S1-PB1-25 1SAM201914R1002 1 0.013
2CDC241005S0014 2CDC131100C0201 - Rev. A
