ABB-free@home®
Sensor unit

Movement detector/switch actuator, 1gang, wireless 1) 2)
With select lens for detection with animal access.
Communication with the free@home system is carried out wireless.
For automatic switching of ABB-free@home® actuators dependent on movement and
brightness. Switch-off delay of the actuator can be programmed via the web interface of the
System Access Point. For switching 127 V~/230 V~ consumers. With integrated switch
actuator. Switching function is available also without prior programming (pre-configured).
Configuration can be changed later via the web interface (groups, scenes, etc.).
The bus can be connected via enclosed terminal block. When installing in the flush-mounted
box, a spatial division between the bus cable and 127 V/230 V installation cable is to be
adhered to! If this minimum distance is not possible, use electronic boxes or insulating tubes.
Bus voltage: 24 V
Outputs: 1x Normally open contact, potential free
Suitable for: ohmic
Rated current: 10 A
Output voltage: 230 V~
Rated power: 2300 W
Suitable for: capacitive
Rated current: 10 AX
Rated power: 2300 VA
Suitable for: inductive
Rated current: 10 AX
Rated power: 2300 VA
Detection range: frontal: 6 m, lateral: 3 m
Detection angle: 180 °
Brightness limit value: 1 Lux - 500 Lux
Mounting height: 1.1 m - 1.3 m
Protection class (Device): IP 20
Temperature range (Device): -5 °C to 45 °C
Dimensions: (L x W x D): 71 mm x 71 mm x 53 mm
Mounting depth: 32 mm
Position for installation: vertical

15
Busch-Duro 2000® SI
Color Bbn Order details Price Weight Pack
4011395 1 piece 1 piece unit
EAN Type code Order code kg pc.
WIRELESS
212 white 215821 MSA-F-1.1.1-212-WL 2CKA006200A0092 1
Reflex SI
Color Bbn Order details Price Weight Pack
4011395 1 piece 1 piece unit
EAN Type code Order code kg pc.
WIRELESS
214 alpine white 215838 MSA-F-1.1.1-214-WL 2CKA006200A0093 1
