Door entry system
ABB-Welcome IP - Outdoor station modules

Info module
Description Info module is used to hold the address of the building or the resident directory and
assembled in outdoor station
Features - Stamped labelling foil is enclosed.
- Backlight ensures clear visibility at night
Technical - Dimensions: 97 x 72 x 25 mm
details - Rating current: 24 V DC, 8 mA
-Operating temperature: -40 °C…+55 °C
Version
Article no. 51381DN
Order no. 2TMA200160N0039

Dummy module
Description Dummy module is one blank module, support to put 3rd-party module inside, also support
to future function module replacement
Features - Maximum space inside: 54.5 x 9.4 x 74 mm
Technical - Dimensions: 97 x 72 x 25 mm
details
Version
Article no. 51381DM
Order no. 2TMA200160N0040

Fingerprint module Available time: Q2,2020
Description Fingerprint module is one access control module of video/audio outdoor station
Features - Enables the opening of the door using a fingerprint scanner
- 64 users can be taught in
- For installing into an ABB-Welcome IP video/audio outdoor station
- Programming directly on the module or using PC management software
(requires 2-wire adaptor M2308)
Technical - Dimensions: 97 x 72 x 28 mm
details - Rating current: 24 V DC, 40 mA
- Operating temperature: -40 °C…+55 °C
Version Stainless steel Aluminum White
Article no. 51381FP-S 51381FP-A 51381FP-W
Order no. 2TMA200160X0003 2TMA200160A0025 2TMA200160W0004
