PROGRAMMABLE LOGIC CONTROLLER - ACCESSORIES
MICRO SMART PLC - FC6A SERIES

CARTRIDGES BASE MODULE
To Suit CPU Module Description Part No.
Plus Cartridge Base Module FC6A-HPH1

FC6A-HPH1
TERMINAL BLOCK CONNECTORS
Terminal
To Suit Type Pitch Pin Part No.
For Plus CPU Module
FC6A-D16_1CEE 3.81mm 10 FC6A-PMTCN10PN02
FC6A-D16R1CEE 3.81mm 11 FC6A-PMTCR11PN02
FC6A-D16K1CEE Screw Fastened 3.81mm 11 FC6A-PMTCK11PN02
FC6A-D16P1CEE 3.81mm 11 FC6A-PMTCP11PN02
FC6A-D16_1CEE 3.81mm 10 FC6A-PMSCN10PN02
FC6A-D16R1CEE Push-In 3.81mm 11 FC6A-PMSCR11PN02
FC6A-D16K1CEE 3.81mm 11 FC6A-PMSCK11PN02
FC6A-D16P1CEE 3.81mm 11 FC6A-PMSCP11PN02
SMART
for All-in-One CPU Module/CAN J1939 All-in-One CPU Module CONTROLLERS &
FC6A-C24_1_E 5.08mm 8 FC6A-PMTA08PN02 AUTOMATION
All CPU modules 5.08mm 9 FC6A-PMTA09PN02
FC6A-C40_1_E_ Screw Fastened 5.08mm 10 FC6A-PMTA10PN02
FC6A-C16_1_E 5.08mm 12 FC6A-PMTA12PN02
FC6A-C24_1_E 5.08mm 13 FC6A-PMTA13PN02

For CAN Communication
CAN J1939 All-in-One Screw Fastened 5.08mm 5 FC6A-PMTE05PN02

For Power Supply
FC4A-PMC20PN02 All CPU Module Screw Fastened 5.08mm 3 FC6A-PMTD03PN02
Plus CPU Module Push-In 5.08mm 3 FC6A-PMSDC03PN02

For Expansion Interface Module
5.08mm 11 FC6A-PMTB11PN02
3.81mm 10 FC6A-PMTC10PN02
Screw Fastened
3.81mm 11 FC6A-PMTC11PN02
3.81mm 17 FC6A-PMTC17PN02
-
5.08mm 11 FC6A-PMSB11PN02
3.81mm 10 FC6A-PMSC10PN02
Push-In
3.81mm 11 FC6A-PMSC11PN02
3.81mm 17 FC6A-PMSC17PN02

For Expansion Interface Mod. Power Supply
Screw Fastened 5.08mm 3 FC6A-PMTB03PN02
FC6A-EXM2/-EXM1S
Push-In 5.08mm 3 FC6A-PMSB03PN02
