PILOT DEVICES
COMPACT RANGE

NON-ILLUMINATED PUSHBUTTONS
Part No. Part No.
Operation Contact Flush Extended
2 NO CP1-10*-20 CP3-10*-20
Momentary 2 NC CP1-10*-02 CP3-10*-02
1 NO + 1 NC CP1-10*-11 CP3-10*-11
2 NO CP2-10*-20 CP4-10*-20
CP1-10R-11 CP2-10G-11 Maintained 2 NC CP2-10*-02 CP4-10*-02
1 NO + 1 NC CP2-10*-11 CP4-10*-11

Colours Red Green Yellow Blue White Black Grey
Replace * with R G Y L W B U
- For chrome bezel and other contact options, please contact IPD.
CP3-10B-11 CP4-10L-20

NON-ILLUMINATED MUSHROOM PUSHBUTTONS

Operation Contact Part No.
Ø 40 mm
Momentary 1NO + 1NC CPM3-10*-11

Colours Red Green Yellow Blue Black
Replace * with R G Y L B
CPM3-10R-11 CPM3-10G-11
- For chrome bezel and other contact options, please contact IPD.

ILLUMINATED PUSHBUTTONS

Part No. Part No.
Operation Description Contact Flush Extended
1 NO CP1-11*-10 CP3-11*-10
24 V AC/DC
1 NC CP1-11*-01 CP3-11*-01
1 NO CP1-12*-10 CP3-12*-10
Momentary 110 – 130 V AC/DC
1 NC CP1-12*-01 CP3-12*-01
1 NO CP1-13*-10 CP3-13*-10
CP1-11R-10 CP1-11G-10 220 V AC/DC
1 NC CP1-13*-01 CP3-13*-01
1 NO CP2-11*-10 CP4-11*-10
24 V AC/DC
1 NC CP2-11*-01 CP4-11*-01
1 NO CP2-12*-10 CP4-12*-10
Maintained 110 – 130 V AC/DC
1 NC CP2-12*-01 CP4-12*-01
1 NO CP2-13*-10 CP4-13*-10
220 V AC/DC
1 NC CP2-13*-01 CP4-13*-01
CP1-11L-10 CP3-11Y-10
Colours Red Green Yellow Blue Clear
Replace * with R G Y L C
- For chrome bezel and other contact options, please contact IPD.
