Visualisation as a
3D building model

Automatic calculation of the separation distance and Free layout of complex buildings
visualisation as a 3D building model To meet the requirements of complex buildings, DEHN
To facilitate the user’s work and to save time, building types Distance Tool allows to adapt a building complex to custom-
can be selected from a picture gallery. After selecting and er needs. Different annexes and roof-mounted structures
activating a building type, the dimensions of the building can be integrated in this building.
can be defined. The separation distances are calculated and
visualised as a 3D building model after selecting the class of
LPS.

Editing a LPS
Mesh sizes often cannot be kept and air-termination sys-
tems have to be adapted to local conditions. The following
changes can be made in the DEHN Distance Tool:

• inserting ring conductors
• adding down conductors
• inserting internal down conductors
• inserting air-termination rods
• inserting or deleting air-termination conductors and
down conductors
• shifting air-termination conductors and down
conductors
• shifting or raising the zero potential level
• inserting measuring points
• inserting points of strike
• inserting texts and notes
