          GAF contactors

          The compact efficient way to switch DC loads




          Optimised for central inverters                                                                             03

          ABB offers the widest range of compact contactors for DC load switching in low
          voltage power distribution applications. Due to their breaking performance for
          DC circuits, GAF contactors can switch DC loads of up to 2050 A 1000 V DC-1.




                  —
                  PV solar plant





                                                                Block contactor
                                                                type GAF


                                                                                        Block contactor
                      PV strings                                                        type AF
                                                               Solar PV
                                                               central inverter











                                           DC                                      AC
                                                                                Grid side
