Protection and control

To keep things running you need control

— — —
02 03 04

Manual motor starters and circuit Contactors and contactor relays Mini contactors
breakers for transformer protection and mini contactor relays

• Fuseless motor protection up to 80 A • 3-pole and 4-pole AC / DC electronic • 2 ranges available: B and M mini contactors
• Designed to perfectly combine with control coil from 9 up to 2850 A AC-1, • Up to 20 A AC-1 / 5.5 kW AC-3 400 V
ABB contactors 500 kW AC-3 • 4 different connecting terminals offered
• Harmonized accessory range • GAF and GF for DC applications • Wide accessories assortment
• UA...UA..RA for capacitor switching
• AFS contactors for safety applications
• ABB Novolink devices: towards the
digitalization for motor starting
solutions

— — — —
05 06 07 08

Contactors and
contactor relays Thermistor protection Smart Monitoring
designed for OEM's Overload relays relays Relays

• Compact and powerful - up • Thermal and electronic type • Monitoring of the winding • Smart temperature moni-
to 7.5 kW AC-3 • Up to 200 A (thermal) and temperature of motors toring relays that can be
• Designed for OEM's 1250 A which have PTC tempera- setup via display or smart-
• Specially suitable for motor (electronic) ture sensors installed phone app
control application • Direct mounting to AF con- • Evaluation of various motor • Measurement of tempera-
tactors conditions such as over- tures using different types
heating, overload and insuf- of sensors, such as PT100,
ficient cooling PT1000, PTC or NTC within
• ATEX approval available for the same time.
the use in hazardous areas • Monitoring of the winding
and bearing temperature of
motors.
