10/115

—
Surface socket outlets
Plastic enclosed

63 A, IP67 Watertight
Plastic enclosure (PBT). Cable entry Ø 32 mm. Cable area 6-25 mm 2

Weight
Terminals/ Color Pkg pkg
Poles code Voltage Frequency Type Order Code qty (1pce)
V Hz kg
2P+E
3  Grey AC 263RS1W 2CMA167310R1000 1 1.00

 50 and 60 263RS4W 2CMA167304R1000
 Yellow 100...130
  Blue 200...250 263RS6W 2CMA167306R1000


 Red 380...415 263RS9W 2CMA167308R1000
3P+E
263RS6W
4  AC 363RS1W 2CMA167324R1000 1 1.07
 Grey
 Yellow 100...130 50 and 60 363RS4W 2CMA167312R1000

  Black 600...690 363RS5W 2CMA167314R1000


 Red 380...415 363RS6W 2CMA167316R1000
10

  Black 480...500 363RS7W 2CMA167318R1000
  Blue 200...250 363RS9W 2CMA167320R1000


 Red 440...460 60 363RS11W 2CMA167322R1000
3P+N+E
5  Grey AC 463RS1W 2CMA167336R1000 1 1.15

 Yellow 100...130
 50 and 60 463RS4W 2CMA167326R1000

  Black 600...690 463RS5W 2CMA126671R1000
 Red
 346...415 463RS6W 2CMA167328R1000
  Black 480...500 463RS7W 2CMA167330R1000

  Blue 208...250 463RS9W 2CMA167332R1000

 Red 440...460 60 463RS11W 2CMA167334R1000

E A
ØF
C1 ØD
C
B

C2

Dimensions (mm)

Type A B C C1 C2 D E F
263-463RS..W 150 263 176 76 76 32 118 8.0
