10/118 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
Surface socket outlets
For looping

32 A, IP67 Watertight
Plastic enclosure (PBT). Cable entry knock-outs 2xØ 25 mm. Terminal block 2x(2.5-10 mm ).
2
Outlet is connected to terminal block.
Weight
Terminals/ Color Pkg pkg
Poles code Voltage Frequency Type Order Code qty (1pce)
V Hz kg
2P+E
3  Grey AC 232RL1W 2CMA168484R1000 1 0.69

 Yellow 100...130
 50 and 60 232RL4W 2CMA168480R1000
432RL6W

  Blue 200...250 232RL6W 2CMA168481R1000
 Red
 380...415 232RL9W 2CMA168482R1000

 Grey transf 232RL12W 2CMA168483R1000
3P+E
 Grey
4  AC 332RL1W 2CMA168494R1000 1 0.70
  Green > 50 V~ >300...500 332RL2W 2CMA168485R1000


 Red 380/440 50/60 332RL3W 2CMA168486R1000
 Yellow 100...130
 50 and 60 332RL4W 2CMA168487R1000
10
  Black 600...690 332RL5W 2CMA168488R1000


 Red 380...415 332RL6W 2CMA168489R1000
  Black 480...500 332RL7W 2CMA168490R1000

  Blue 200...250 332RL9W 2CMA168491R1000
  Green > 50 V~ 100...300 332RL10W 2CMA168492R1000

 440...460 60 332RL11W 2CMA168493R1000
 Red
3P+N+E
5  Grey AC 432RL1W 2CMA168502R1000 1 0.72


  Green > 50 V~ >300...500 432RL2W 2CMA168495R1000
 Red 380/440 50/60 432RL3W 2CMA168496R1000


 Yellow 100...130 50 and 60 432RL4W 2CMA168497R1000
 Red 346...415 432RL6W 2CMA168498R1000


  Black 480...500 432RL7W 2CMA168499R1000
  Blue 208...250 432RL9W 2CMA168500R1000

 Red
 440...460 60 432RL11W 2CMA168501R1000
120
90 Ø 4.2 Ø 25x2
170
253

149
