11/88 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
pure stainless steel
Rocker switches / push switches

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Rocker Switch Mechanism ) 1 Rocker Switch Mechanism ) 1
Rated voltage: 250 V~ 2gang 2way
Rated current: 10 AX With screwless terminals.
Protection class (Device): IP 20 Rated voltage: 250 V~
IEC 60669-1 Rated current: 16 AX
Protection class (Device): IP 20IEC 60669-1
2400/6/6US-101-500 2CKA001022A0663 10
1gang 2way
1) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
2000/6 US-500 2CKA001012A2198 10/100 Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
or 3060 wallbox concrete)
2gang 1way
2000/5 US-500 2CKA001012A1150 10/100
Rocker Switch Mechanism ) )
2
1
DP, 1gang 1way
2
DP, 1gang 2way )
For switching high loads.
2000/6/2 US 2CKA001012A0954 10 Rated voltage: 250 V~
Rated current: 16 AX
1gang Protection class (Device): IP 20IEC 60669-1
2000/7 US-500 2CKA001012A2199 10/100
2000/2 US-101-500 2CKA001012A2193 10/100
DP, 1gang 1way 1) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
2000/2 US-500 2CKA001012A2196 10/100 or 3060 wallbox concrete)
2) Also for switching SCHUKO® socket outlets.
SP, 1gang 1way switch
2000/1 US-500 2CKA001012A2059 10/100
Rocker Switch Mechanism ) )
1
2
11
1) Only in conjunction with standard flush-mounting boxes according to DIN 49073, 3-pole, 1gang 1way switch
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall Rated voltage: 400 V~
or 3060 wallbox concrete)
2) With screw-type terminals. Non-illuminable. Rated current: 16 AX
Protection class (Device): IP 20IEC 60669-1
Rocker Switch Mechanism ) 1
Rated voltage: 250 V~ 2000/3 US 2CKA001011A0816 10
Rated current: 16 AX 1) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
Protection class (Device): IP 20 Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
IEC 60669-1 or 3060 wallbox concrete)
2) With screw-type terminals. Non-illuminable.
1gang 2way Rocker Switch Mechanism, control )
1
2gang 1way
2400/6 US-500 2CKA001012A2232 10/100
with LED,
2gang 1way Rated voltage: 250 V~
Rated current: 16 AX
2400/5 US-500 2CKA001012A2234 10 Protection class (Device): IP 20IEC 60669-1
1gang 2400/5 USK-500 2CKA001012A2238 10
2400/7 US-500 2CKA001012A2236 10 1) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
1) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall or 3060 wallbox concrete)
or 3060 wallbox concrete)
Rocker Switch Mechanism ) 1
Rocker Switch Mechanism ) 1 With neon lamp 8338-1.
2gang 2way Rated voltage: 250 V~
With screwless terminals. Rated current: 10 AX
Rated voltage: 250 V~ Protection class (Device): IP 20
Rated current: 10 AX IEC 60669-1
Protection class (Device): IP 20IEC 60669-1
1gang 2way )
2
2000/6/6US-101-500 2CKA001011A0928 10/100
2000/6 USGL-500 2CKA001012A2194 10/100
1) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall 2gang 1way
or 3060 wallbox concrete)
2000/5 USGL 2CKA001012A1135 10
1) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
or 3060 wallbox concrete)
2) Replacement lamps 8360, 8362, and 8363 and LED inserts.
