11/124 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
pure stainless steel
WaveLINE control elements Accessories

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

2
1
Wall-mounted transmitter WaveLINE ) ) ) Extension of claws )
1
3
4-channel For the installation of flush-mounted SCHUKO® socket
4gang wall-mounted transmitter independent of mains outlets and also switches, push-buttons, etc. and deeply
power supply. installed flush-mounted boxes.
With labelling field and labelling strip. Protection class (Device): IP 20
For switching and dimming.
For controlling blinds and light scenes.
4 radio channels can be operated or up to 8 light scenes 2148 2CKA002148A0120 100
can be called up. 1) Not suitable for types 2000/3 US, 2000/6/2 US, 2000/6/6 US-101 and double
For flush-mounted WaveLINE actuators 6701-101, 6702, socket outlets.
6703, 6704 and 6705-101.
For LED display WaveLINE 6730-xxx.
Compatible with WaveLINE KNX gateway TP-RF 6770. Braille symbol
Send frequency: 868 MHz. self-adhesive (transparent) for cover 2506-xxx
Free-field range: approx. 100 m. Protection class (Device): IP 20
Power supply: lithium button cell battery Type CR2032.
Battery service life: typically 5 years, therefore
practically maintenance-free.
Automatic monitoring of battery life.
Including fixing plate for mounting on smooth walls or light
on switch boxes. 2144 LI 2CKA001714A0295 10/1000
Surface painted.
Control element: rocker switch left/right bell
Display elements: LED to indicate the transmission 2144 KI 2CKA001714A0296 10/1000
Rated voltage: 3 V-
Protection class (Device): IP 20 key
Temperature range (Device): -5 °C to 45 °C
11
Dimensions: (L x W x D): 63 mm x 63 mm x 16 mm 2144 TR 2CKA001714A0297 10/1000
stainless steel 6733-866-500 2CKA006730A0043 1/10
1) Battery included in delivery. Braille symbol
2) For compatible lettering software, visit www.BUSCH-JAEGER-labelingtool.com. socket outlet
3) Surface painted. self-adhesive, transparent for SCHUKO® socket outlets
with hinged lid 20 EUK-xxx
Protection class (Device): IP 20
3
1
2
WaveLINE LED display ) ) )
For status display of window handle positions: open =
red, closed = green, tilted = yellow. 2144 ST 2CKA001714A0298 10/1000
Direct onsite operation possible for switching /
dimming an electrical device depending on the flush-
1
mounted insert. DIN A 4 labelling sheet )
4 individual LED display channels. plastic foil
Up to 8 WaveLine transmitters can be taught-in on each Suitable for all to be labeled Busch-Jaeger devices.
LED display channel. For laser printer.
Up to 8 WaveLine transmitters can be taught-in on The text of the foil is printed via the Busch-Jeager
onsite operation. labeling service.
After a power cut all LED-Display channels light in red.
The cyclic telegram repeat of the WaveLINE window translucent 1799/02 2CKA001799A0959 1
position sensor 6720-xxx sensor automatically updates transparent 1799/03 2CKA001799A0960 1
the window open state. 1) 1 piece = 1 sheet.
Status display for depleted WaveLINE transmitter
battery.
Status display for faulty transmission link and defective RC suppressor
WaveLINE transmitter. For protection against the damage or destruction of
User-friendly start-up without PC / software. electronic devices due to overvoltages.
Printed labelling sheet with 8 different inlay sheets. For wiring network-interconnected inductivities (e.g..
For WaveLINE window position sensor 6720-6x. relay, protection, fluorescent lamps, transformers, etc.).
For WaveLINE 6721-xx universal signalling unit. Eliminates functional disturbances on electronic
For Busch-Watchdog 220 WaveLINE 6747 AGM. devices, e.g. automatic circuit reclosure (clocking) of a
For Busch-Universal relay switch insert 6404 U. movement detector.
For universal dimmer switch insert 6595 U. Dimensions: diameter 25 mm, length 35 mm, length of
Free-field range: approx. 100 m. the connecting cable approx. 100 mm.
Send/receive frequency: 868 MHz. Rated voltage: 230 V~, +10 % / -10 %
Surface painted. Rated frequency: 50 Hz
Protection class (Device): IP 20 6899 2CKA006899A0231 10
Temperature range (Device): -5 °C to 45 °C
Dimensions: (L x W x D): 63 mm x 63 mm
stainless steel 6730-866 2CKA006730A0023 1
1) For compatible lettering software, visit www.BUSCH-JAEGER-labelingtool.com.
2) Surface-painted
3) Surface painted.
