Room thermostats

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

2
1
Room thermostat, flush-mounted ) ) Cover plate
Change-over contact, setpoint indication, timer, for room thermostat
remote sensor For room thermostats 1094 U, 1097 U.
With change-over contact. Surface painted.
Easy adjustment using menu and text-based display.
4 switching times per day can be user-defined for each
day of the week.
With fixing claws. stainless steel 1794-866 2CKA001710A3755 10
Automatic summer/wintertime switch-over
Remote sensor cable length: 4 m. Cover plate
Sensor =NTC, 10 kilo-ohm at 25 degrees C. for room thermostat
Power reserve > 10 hours With sliding switch for nightly room temperature
To fit cover plate 6435-xxx. reduction.
Class of temperature controller 1 to activate nighttime mode and reduction of room
Contribution to space heating energy efficiency 1,0%. temperature by 4K, for thermostats 1095 U, 1096 U and
Rated voltage: 230 V~ 1095 UF.
Rated current: 16 A Surface painted.
Temperature range (Device): 10 °C to 50 °CEN 60730-2-9
stainless steel 1795-866 2CKA001710A3756 10
1098 UF-101 2CKA001032A0509 1/10
1) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall Cover plate
or 3060 wallbox concrete) for room thermostat
2) Servo valves of "closed or open when de-energized“ design are required for the For room thermostats 1094 UTA, 1097 UTA.
controller. E.g. article no. 6164/10-101. Surface painted.

3
Room thermostat, flush-mounted ) ) )
1
2
11
Heating/cooling stainless steel 1794 TA-866 2CKA001710A3761 10
With separate connection (230 V~) for external
switchover between heating or cooling.
Switch contact opens when the set temperature is Cover plate
reached. for room thermostat
With fixing claws. With sliding switch for nightly room temperature
Nominal current: 10 A heating reduction.
Nominal current: 5 A cooling For room thermostats 1095 UTA, 1096 UTA.
Class of temperature controller 1 Surface painted.
Contribution to space heating energy efficiency 1,0%.
Rated voltage: 230 V~ stainless steel 1795 TA-866 2CKA001710A3762 10
Temperature range (Device): 5 °C to 30 °CEN 60730-2-9,
British Standard EN 60669-2-1
Cover plate )
1
1099 UHK 2CKA001032A0515 1/10 For comfort timer control element 6455-101-500.
1) Only in conjunction with standard flush-mounting boxes according to DIN 49073, For standard timer control element 6456-101.
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall For room thermostats 1098 U-101 and 1098 UF-101.
or 3060 wallbox concrete) For short-time timer 6465 U-101.
2) Servo-valves, "closed when de-energized", are necessary for connection to For Busch-CO2 sensor 1091 U-500.
thermostat. e.g. Article No. 6164/10-, see KNX chapter. Surface painted.
3) Switching temperature difference: ± 0.5 K.
stainless steel 6435-866 2CKA006430A0344 10
1) Surface painted.
Room thermostat, flush-mounted ) ) )
2
1
3
Heating/cooling, sliding switch
With built-in sliding switch for switchover between Cover plate
cooling or heating. for room thermostat
Switch contact opens when the set temperature is For room temperature controller 1099 UHK.
reached. Surface painted.
With fixing claws.
Nominal current: 10 A heating
Nominal current: 5 A cooling
Class of temperature controller 1 stainless steel 1795 HK-866 2CKA001710A4018 10
Contribution to space heating energy efficiency 1,0%.
Rated voltage: 230 V~ Cover plate
Temperature range (Device): 5 °C to 30 °CEN 60730-2-9, for room thermostat
British Standard EN 60669-2-1
For room temperature controller 1099 UHKEA.
1099 UHKEA 2CKA001032A0516 1/10 With sliding switch for switchover between cooling or
1) Only in conjunction with standard flush-mounting boxes according to DIN 49073, heating.
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall Surface painted.
or 3060 wallbox concrete)
2) Servo-valves, "closed when de-energized", are necessary for connection to stainless steel 1795 HKEA-866 2CKA001710A4050 10
thermostat. e.g. Article No. 6164/10-, see KNX chapter.
3) Switching temperature difference: ± 0.5 K.
