solo®
Data communication

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Built-in jack Cover plate )
1
For potential balancing jack cover plate and installation 2gang
in cover plates. As cover for universal data connection boxes.
For devices of 19 mm diameter. Art. No. 0214, 0215 (Cat 3), 0220/12-507, 0221/12-507,
Protection class (Device): IP 20 0218, 0217 (Cat 5e/6 data technology) and comparable
types of the company Rutenbeck.
Brand-Rex (WAEGV 8/8 EKR/EK).
0471-0-0037 2CKA000471A0037 10 AMP (NETCONNECT 5E).
BTR (E-DAT C6, E-DAT design, Universal data connecting
unit design and IAE design).
Potential balancing plug
Suitable for plug 2095 UC-212 and built-in jack 0471-0- cti (cti-wire 2.8 Cat.6).
0037 acc. to German Standard DIN 42801. Telegärtner (AMJ 45, UMJ 45).
For potential balancing jack cover plate (connection up With down-leading outlet.
to 6 mm² crimped or soldered) With labelling field.
Protection class (Device): IP 20 Size of labelling field: 60 x 9 mm.
Protection class (Device): IP 20
0299-0-0032 2CKA000299A0032 10 ivory white 1803-02-82 2CKA001710A3146 10
studio white 1803-02-84-500 2CKA001710A1551 10/100
Blank plate grey metallic ) 2 1803-02-803 2CKA001710A3853 10
with metal mounting plate
Protection class (Device): IP 20 1) For compatible lettering software, visit www.BUSCH-JAEGER-labelingtool.com.
2) Surface painted.
Cover plate
For telephone connection unit.
ivory white 1742-82 2CKA001710A3143 10
For USB, VGA, HDMI inserts and communication
11
studio white 1742-84-500 2CKA001710A3991 10/100 adapter.
1
grey metallic ) 1742-803 2CKA001710A3843 10 For loudspeaker connection box.
USB power adapter insert 6472 U.
1) Surface painted.
Suitable for part number 0248/0x-101.
For data modules.
Cover plate ) 1 Suitable for Art. No. 0219/12 and 0219/13.
with metal mounting plate For modular outlets with 90° RJ45 outlet from
As cover for flex outlet, for cords up to 10.3 mm Telegärtner (type MJ and WE).
diameter. Protection class (Device): IP 20
With strain relief (without terminal block). ivory white 1766-82 2CKA001710A3144 10/100
Protection class (Device): IP 20
studio white 1766-84-500 2CKA001710A3992 10/100
ivory white 1749-82 2CKA001710A3145 10 grey metallic ) 1 1766-803 2CKA001710A3854 10
studio white 1749-84 2CKA001710A3163 10/100 1) Surface painted.
grey metallic ) 1749-803 2CKA001710A3844 10
2
1) Cover plate can also be used individually as cover for telephone connector boxes Cover plate
(VDo). As cover for telephone connector boxes (VDo).
2) Surface painted.
Can be knocked out for single or double connection.
Protection class (Device): IP 20
Cover plate ) 1
As cover for universal data connection boxes.
Art.-No. 0213 (Cat 3/ISDN), 0216-101, 0218/11-101 (Cat ivory white 1745-82 2CKA001710A3155 10
5e/6 data technology) and comparable types of the
company Rutenbeck. studio white 1745-84 2CKA001710A3173 10
For WLAN access points 8186/31 and 8186/41. grey metallic ) 1 1745-803 2CKA001710A3855 10
Brand-Rex (WAEGV 8 EKR/EK).
1) Surface painted.
BTR ( universal data connecting unit design and IAE
design).
Telegärtner (AMJ 45, UMJ 45). Cover plate )
1
With down-leading outlet. socket outlet
With labelling field. Telephone socket (TDO)
Size of labelling field: 60 x 9 mm.
Protection class (Device): IP 20
ivory white 1803-82 2CKA001710A3147 10
studio white 1803-84-500 2CKA001710A1550 10/100 ivory white 1762-82-506 2CKA001710A4104 10/100
grey metallic ) 1803-803 2CKA001710A3852 10 studio white 1762-84-506 2CKA001710A4106 10/100
2
1) For compatible lettering software, visit www.BUSCH-JAEGER-labelingtool.com. grey metallic ) 2 1762-803-506 2CKA001710A4102 10/100
2) Surface painted.
1) Suitable insert: TDO 3x 10 OUP (for 1 telephone and 2 auxiliary devices).
2) Surface painted.
