solo®
Multimedia / communication adapters

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

1
Busch-powerDock Charging cradle with USB-C USB charging station insert ) ) )
3
2
connection For supply and support of mobile devices via USB-cable.
For Busch-powerDock insert 6473 U. With micro USB connecting cable.
For attaching mobile terminal devices with USB-C Connecting cable joined captive to insert.
connection. Usable cable length (incl. micro USB plug) approx.
Temperature range (Device): 5 °C to 35 °C 22 cm.
Dimensions: (L x W x D): 54 mm x 54 mm x 36 mm With electronic short-circuit protection.
With electronic overload protection.
6473/11-500 2CKA006400A0083 1/10
Rated voltage: 100 - 230 V~, +10 % / -10 %
Secondary: 5 V-, +5 % / -5 %
USB power adapter insert, flush-mounted ) ) ) ) Rated frequency: 50 Hz - 60 Hz
1
3
2
4
For supply and support of mobile devices via USB-cable. Rated current: 1400 mA
With two USB type A outputs. Protection class (Device): IP 20, SELV
To support two devices at the same time. Temperature range (Device): 5 °C to 40 °C
With electronic short-circuit protection. Dimensions: (L x W x D): 71 mm x 71 mm x 35 mm
With electronic overload protection. Mounting depth: 32 mm
Rated voltage: 100 - 230 V~, +10 % / -10 % 6474 U-500 2CKA006400A0033 1/10
Secondary: 5 V-, +5 % / -5 % 1) No claw. Screw-fixing via keyholes.
Rated frequency: 50 Hz - 60 Hz 2) No data transfer.
Suitable for: In case one output is used: 3) For terminal devices with standardized charging interface according to DIN EN
Rated current: 1400 mA 62684.
Suitable for: In case two output are used:
Rated current: 700 mA
1
Protection class (Device): IP 20, SELV HDMI connection unit )
Temperature range (Device): 5 °C to 40 °C with screw-type terminals and strain relief
Dimensions: (L x W x D): 71 mm x 71 mm x 43 mm Suitable for telephone connection unit cover plates 11
Mounting depth: 32 mm 2539-21x and 1766-xxx.
To link high-definition digital audio and video data from
6472 U-500 2CKA006400A0002 1
e.g. SAT-receiver, DVD-/Blue-Ray-player to plasma-type,
1) No claw. Screw-fixing via keyholes. LCD- or-LED-TVs/screens.
2) No data transfer. HDMI-type A, 3D-compatible.
3) For terminal devices with standardized charging interface according to DIN EN Fully HD ready (1920 x 1080 pixel).
62684.
4) Use dust cover 2098 when cleaning the device. For 20-wire HDMI-cables via srew-type terminals.
For trunk systems, flush-mounted wall boxes and
underfloor systems.
USB power adapter insert, flush-mounted ) ) ) ) For easy installation and to follow the valid bending
1
2
4
3
For supply and support of mobile devices via USB-cable. radii the "Kaiser- electronic-wall-box" type 1068-02 or
With two USB type A outputs. 9062-74 is recommended.
To support two devices at the same time. Without cover plate.
With electronic short-circuit protection. Without claws.
With electronic overload protection. Protection class (Device): IP 20
Rated voltage: 120 - 230 V~, +10 % / -10 % Mounting depth: 34 mm
Secondary: 5 V-, +5 % / -5 %
Rated frequency: 50 Hz / 60 Hz white 0261/31-500 2CKA000230A0430 1
Suitable for: In case one output is used: grey 0261/33-500 2CKA000230A0432 1
Rated current: 3 A alpine white 0261/32-500 2CKA000230A0431 1
Suitable for: In case two output are used:
Rated current: 1.500 mA 1) Please follow the recommendations of the cable and device producers for the max.
Protection class (Device): IP 20, SELV HDMI cable lengths.
Temperature range (Device): 0 °C to 35 °C
Dimensions: (L x W x D): 71 mm x 71 mm x 43 mm
Mounting depth: 32 mm
Available from November 2019
6472 U-500-101 2CKA006400A0094 1
1) No claw. Screw-fixing via keyholes.
2) No data transfer.
3) For terminal devices with standardized charging interface according to DIN EN
62684.
4) Use dust cover 2098 when cleaning the device.
