Unno
Selected functions

01 02 03 04 05 06 07

08 09 10 11 12 13 14

01 1-gang, 1-way single pole switch 06 Universal rotary dimmer 11 Nema simple socket outlet
02 1-gang, 2-way single pole switch with lamp 07 RJ11 telephone outlet 12 Nema duplex socket outlet
03 1-gang, 1-way push switch with bell symbol 08 Type F TV outlet 13 Brazilian 10A socket outlet
04 1-gang, 1-way double pole 32A switch 09 RJ45 Cat. 5E data outlet 14 Brazilian 20A socket outlet
05 Buzzer 10 Cable outlet 11

01 04 07 10
Frames 4" × 2"
01 Blank frame, 80 × 115 mm
02 Frame 1 module vertical position, 80 × 115 mm
03 Frame 1 module, 80 × 115 mm
04 Frame 2 modules, 80 × 115 mm
05 Frame 1+1 modules, 80 × 115 mm
06 Frame 3 modules, 80 × 115 mm
02 05 08 11
Frames 4" × 4"
07 Blank frame, 128 × 115 mm
08 Frame 1+1 modules, 128 × 115 mm
09 Frame 2+2 modules, 128 × 115 mm
10 Frame 1+1+1+1 modules, 128 × 115 mm
11 Frame 3+3 modules, 128 × 115 mm

03 06 09
