Page 1664 - Din prodcuts 2020

11/558 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
Unno
Rocker switches

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Switch 1-gang, 1-way, SP - 1 M Push-button, SP with bell symbol - 1M
Rated voltage: 110 - 250 Vac. Rated voltage: 110 - 250 Vac.
Rated current: 10 AX. Rated current: 10 AX.
Screw terminals. Screw terminals.
Optional: locator LED lamp N1191 BL (127 Vac). Optional: locator LED lamp N1191 BL (127 Vac).

White N1101 BL 2CLA110100N1103 30 White N1104 BL 2CLA110400N1103 30
White/Black N1101 BN 2CLA110100N1803 30 White/Black N1104 BN 2CLA110400N1803 30

Switch 1-gang, 2-way, SP - 1 M Locator LED lamp kit - 127 Vac - 1M
Rated voltage: 110 - 250 Vac. Suitable for all the switches and push buttons.
Rated current: 10AX. White light.
Screw terminals. Rated voltage: 110 - 250 Vac.
Optional: locator LED lamp N1191 BL (127 Vac). Rear connection with 2 cables.
Rated current: <0,2 mA. Specially designed for CFL and
LED lamps.
White N1102 BL 2CLA110200N1103 30
White/Black N1102 BN 2CLA110200N1803 30 White N1191 BL 2CLA119100N1003 10

Switch 1-gang, intermediate, SP - 1 M
Rated voltage: 110 - 250 Vac.
Rated current: 10 AX.
Screw terminals.
Optional: locator LED lamp N1191 BL (127 Vac).
11
White N1110 BL 2CLA111000N1103 30
White/Black N1110 BN 2CLA111000N1803 30

Switch 1-gang, 1-way, DP - 1 M
Rated voltage: 110 - 250 Vac.
Rated current: 20 AX.
Screw terminals.

White N1101.7 BL 2CLA110170N1103 5
White/Black N1101.7 BN 2CLA110170N1803 5

Switch 1-gang, 1-way, SP - 1 M
Rated voltage: 110 - 250 Vac.
Rated current: 10 AX.
Screw terminals.
Included: locator LED lamp N1191 BL (127 Vac).

White N1101.3 BL 2CLA110130N1103 30
White/Black N1101.3 BN 2CLA110130N1803 30

Switch 1-gang, 2-way, SP - 1 M
Rated voltage: 110 - 250 Vac.
Rated current: 10 AX.
Screw terminals.
Included: locator LED lamp N1191 BL (127 Vac).

White N1102.3 BL 2CLA110230N1103 30
White/Black N1102.3 BN 2CLA110230N1803 30
