Page 1679 - Din prodcuts 2020

11/573

—
IVIE
Movement detectors Buzzer / Door bell

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

110° motion sensor Buzzer & door bell
Number of modules: 2 Buzzer
Max. power: Number of modules: 2
- Incandescent: 1.800W @230V AC/1.000W @127V AC
- Halogen with electronic o ferromagnetic transformer:
750VA @230V AC/400VA @127V AC
- Fluorescent lamps or motors: 400VA @230V AC/
200VA @127V AC white IIM2BUZR BL 1SYK100001A1054 5/100
For automatic switching of devices dependent on anthracite grey IIM2BUZR AN 1SYK100001A1254 5/100
motion and brightness silver IIM2BUZR PL 1SYK100001A1154 5/100
With integrated selector switch for automatic ON-OFF
in the front side
Switch-off delay: 10 sec. to 10 min. or short-time pulse Buzzer
1 sec adjustable (from the front side) Number of modules: 1
Detection range: 5 m radius
Adjustable light set point level for activation (from the
front side)
Detection angle: 110°
Mounting height: 1, 2 m auxiliary control with N2X04.X white N2119 BL 2CLA211900N1102 1
push-buttons
anthracite grey N2119 AN 2CLA211900N1802 1
white N2241 BL 2CLA224100N1102 1
silver N2119 PL 2CLA211900N1302 1
anthracite grey N2241 AN 2CLA224100N1802 1
silver N2241 PL 2CLA224100N1302 1
Buzzer
Number of modules: 2
11

white N2219 BL 2CLA221900N1102 1
anthracite grey N2219 AN 2CLA221900N1802 1
silver N2219 PL 2CLA221900N1302 1

Electronic door bell 230 V AC
Number of modules: 2

white N2224 BL 2CLA222400N1102 1
anthracite grey N2224 AN 2CLA222400N1802 1
silver N2224 PL 2CLA222400N1302 1
