Simply effortless

This saves valuable labour time

Now easier than ever. Only a few components are needed to install
ABB-free@home®. For the direct activation of light, the entire system
only requires a bus cable, the sensor/actuator unit, a power supply and
a System Access Point for programming.

— — — — —
01 02 03 04 05

—
01 System Access Point
—
02 Sensor, 1gang
—
03 Switch actuator, 4gang
—
04 Binary input, 2gang, flush-mounted
—
05 Power supply

The System Access Point The actuators and sensors
The nerve centre of the ABB-free@home® system is the Actuators for switching, dimming and control are available
15
System Access Point. It provides access for computer, tablet for ABB-free@home®. The flush-mounted binary inputs also
or smartphone via WLAN. This allows the functions of the allow the integration of conventional switches and devices,
system to be defined and remotely controlled – even after such as window contacts, for example. Push-buttons, room
installation. The System Access Point can also be combined temperature controllers and movement detectors are avail-
with a network router – via LAN or WLAN. Just connect and able as sensors.
you’re done. For convenience, the System Access Point
creates its own WLAN and the software necessary for
project planning and commissioning is already on board.
This makes you independent from the structural conditions
and no additional software is required. As soon as you are
finished with programming you can save the status and
restore it again at any time.
