15/13

—
ABB-free@home®
System devices

free@home window sensor, wireless 1) 2)
For monitoring of the current window handle position.
The status can be visualized on the free@home panel and in the free@home app.
The window sensor is installed between the existing window handle and the window frame.
Existing window handle is used.
Suitable for window handle: 7 mm square fastener, 43 mm
attachment screw separation, lifter dia. 10 and 12 mm, max.
mounting plate size 34 x 77 mm (WxH). No wire laying required.
Mounting accessories (square extension, screws, adapter for cams) are included.
Battery included.
Low Battery notification via the free@home app.
Protection class (Device): IP 43
Temperature range (Device): -5 °C to 50 °C
Dimensions: (L x W x D): 168 mm x 38 mm x 13 mm

Bbn Order details Price Weight Pack
WIRELESS 4011395 1 piece 1 piece unit
EAN Type code Order code kg pc.
64 studio white matt 215906 WBI-S-1-64-WL 1
65 basalt black 215920 WBI-S-1-65-WL 2CKA006200A0103 1
66 stainless steel 232484 WBI-S-1-66-WL 2CKA006200A0142 1

free@home universal detector, wireless 1) 2)
For monitoring of the state (open, closed) of windows, skylights, doors and gates with
a magnetic contact.
Additional connection option for an external, potential-free sensor
(choice of normally closed or normally open contact).
The status can be visualized on the free@home panel and in the free@home app. 15
The magnetic contact and the potential-free input can be monitored separately.
The universal detector and the magnets are fixed with adhesive film or screws.
Accessories (adhesive foil, screws, magnet) included in delivery.
Battery type: CR2
Low Battery notification via the free@home app.
External sensor max. wire length: 5 m
External sensor terminal connection diameter : 0.14...0.5 mm² (single wire)
Protection class (Device): IP 43
Temperature range (Device): -5 °C to 50 °C
1) Programming only Dimensions: (L x W x D): 118 mm x 30 mm x 22 mm
with bus
voltage applied via the
web inter-
face of the System
Access Point. WIRELESS Bbn Order details Price Weight Pack
2) Additional informa- 4011395 1 piece 1 piece unit
tion about
commissioning and EAN Type code Order code kg pc.
operation is
contained in the system 64 studio white matt 215913 BI-S-1-64-WL 2CKA006200A0102 1
manual 65 basalt black 215937 BI-S-1-65-WL 2CKA006200A0104 1
and the online operating
manual
of the current
e-catalogue.
