16/26 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
Door entry system
ABB-Welcome - Indoor stations

4.3" video hands-free indoor station with induction loop
• Electromagnetic signals will be emitted by a special inductive loop for auditory indication
of any incoming calls. Functionable for users with hearing aids.
• 4.3" color display with on screen display.
• 6 touch film buttons for communication, unlocking, mute, programmable button
(can be set as intercom, call guard unit, etc.), surveillance and setting.
• 2 photos of the visitor will be automatically stored in memory for door calls during
resident‘s absence.
• Holds up to 50 photos.
• Call transfer among different apartments and guard unit is available.
• Doctor function for automatic unlock.
• 5 ringtones for different call sources, i.e. from default outdoor station, secondary outdoor
station, door bell, intercom or guard unit.
• Broadcast by simply pressing and holding the communication button.
• Surface mounting, flush mounting (flush mounted box 42311F is needed), desktop
mounting (desktop bracket 42311D is needed) and cavity wall set (51021CS needed).
• The detailed user manual can be downloaded through scanning the QR code on the screen.
• Product dimensions: 137 x 155 x 24 mm.

Article No. Order No. Description Pack Qty
M22313-W 4.3" hands-free video indoor station, induction loop, white 1/28

Video indoor station 4.3", DES+APP, WiFi
New 2-wire video indoor station with integrated WiFi to connect mobile APP without
additional system devices. Minimalistic & intuitive user interface makes the operation simply
enough. 6 touch buttons are easy for operation and one side button to adjust volume,
ringtone, brightness and others. You can also accept the call, open the door lock, make
a surveillance, and firmware updating and additional activations from the Welcome APP.

Features:
• Intuitive GUI on 4.3” IPS screen (resolution: 480 x 272)
• Intuitive button layout, separate “call” & “unlock” button, to avoid mis-operation on small
size panel
• Slim thickness with 18mm
• Surface-mounted installation with one metal bracket
• Network/WiFi connection & parameters of panel can be configured through Welcome APP
following wizard design
16
• APP pairing process is easy enough to scan QR code for first mobile devices, and click
“pair” button for additional mobile devices with same MyBuildings account login
• Up to 8 mobile devices can be paired with one panel through same MyBuildings account
• Cyber security and data privacy
• Remote firmware update through Welcome APP

Article No. Order No. Description Pack Qty
M22401-W 2TMA220050W0022 Video indoor station 4.3", DES+APP, WiFi
M22403-W 2TMA220050W0024 Video indoor station 4.3", DES+APP, WiFi, T-loop
