21/4 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
Enclosures
Livorno Series emergency consumer units

Consumer units, technical specifications

Protection class IP40, IP55 or IP65, according to version.
Version flush- and wall-mounting.
Colour RAL 3000 red and RAL 7035 grey.
Installation temperature -25°C ÷ +60°C.
Resistance to heat ball thermopressure up to +85°C according to EN 60695-10-2 standard.
Front door breakable glass 0.75 (IK05 degree).
Material self-extinguishing thermoplastic material, resistant to abnormal heat and fire
up to 650°C (glow wire test), according to IEC 60695-2-11 standard.
Door lock coded-type key
Included accessories module covers (per DIN rail versions)
4 screw cover plugs
certification plate

Consumer units with emergency button, technical specifications
Protection degree IP55.
Version flush- and wall-mounting
Colour RAL 3000 red.
Installation temperature -25°C ÷ +60°C.
Rated operating voltage Ue 250 V.
Utilisation category AC 12.
Rated operating voltage Ie 2 A.
Rated insulation voltage Ui 250 V.
Pollution degree 3.
Fuses 10 A, gG type, 10.3x38 mm.
Front door breakable glass 0.75 (IK05 degree).
Material self-extinguishing thermoplastic material, resistant to abnormal heat and fire
up to 650°C (glow wire test), according to IEC 60695-2-11 standard.
Luminous button with 1 NO contact + 1 NC contact (2 A, 250 V).
Included accessories glass-breaking hammer.
Optional accessories 12 or 24 V bulb lamp (incandescent), or 250 V (fluorescent).
Conformity EN 60947-5-1 standard.
Mark of approval IMQ according to EN 60947-5-1
