ADVANCED SMART SOFT STARTER - EMX4i SERIES

1000V/1200V EMX4i SOFT STARTER
Features: Current Rating (A) IP Frame
- Intelligent adaptive start/stop control. Light Medium Heavy Severe Rating Size Part No.
- Extended motor protection functionality.
- USB port and QR trip code. 202 165 140 121 EMX4i0202EV12*
- Automation functions with optional smart card. 287 233 197 168 EMX4i0287EV12*
- IOS and Android support App. 387 315 267 229 EMX4i0387EV12*
564 444 366 299 IP00 S4 EMX4i0564EV12*
629 503 414 339 EMX4i0629EV12*
857 677 559 460 EMX4i0857EV12*
1092 865 716 591 EMX4i1092EV12*
- 2 starts per hour, 40°C, <1000m.
- MV soft starter (up to 15kV) is also available. Please contact IPD for details.
- Must be used with external bypass.
- Higher rating available on request- Please contact IPD. SOFTSTARTERS

* To complete Part Number, add the required voltage code:
Code C1H C2H
S4 Control Voltages 110/240V AC 24V AC/DC

Duty Category: EMX4i-0202E~1092E - Light : AC53b 3.0-10:1790 : 40°C, < 1000m - Medium : AC53b 3.5-15:1785 : 40°C, < 1000m
- Heavy : AC53b 4.0-20:1780 : 40°C, < 1000m - Severe : AC53b 4.5-30:1770 : 40°C, < 1000m

ACCESSORIES
COMMUNICATION CARDS
Description Part No.
DeviceNet Card EMX4 PICDN01
Ethernet IP Card EMX4 PICEI01
Modbus TCP Card EMX4 PICMT01
Modbus RTU Card EMX4 PICMB01
PICDN01 Profibus Card EMX4 PICPB01
Profinet Card EMX4 PICPN01

FINGERGUARDS CARDS

Description Part No.
Fingerguard 0184B-0580B (It's a kit. 1 for each starter) 9951730900
FINGERGUARDS
REMOTE KEYPADS
Description Part No.
Remote, Keypad Card EMX4 PICRC01
Remote Keypad Card & Keypad EMX4 PICRC02
Remote Keypad EMX4 PICRK01
Note: the above 3 parts come with remote keypad mounting kit (c/w 3m interface cable).
KEYPAD
SMART CARDS

Description Part No.
Smart Card Pump Applicaton EMX4 SCCPC01
- The smart card come with 4xDI, 1xRTD/PT100, 3x4-20mA inputs for (depth, pressure or flow
transducers).
SMART CARDS
