ORDER INFORMATION

BUSBAR HOLDER

SKINNEHOLDER

BHAIS support (refer page 2:25) has to
be used with BHAI holder for horizontal
Cu arrangement
2 TYPE DESCRIPTION BB HOLDER Cu SIZE CONDUCTORS CENTERS WEIGHT ORDER No.
MAX. QTY.
MAX.
PHASE
LENGTH
(kg)
PER PHASE
Cu BHAI 8 BUSBAR HOLDER 800 10×100 6 85 2.50 20628
3.12
20634
BHAI 10 BUSBAR HOLDER 1000 10×150 6 115 WEIGHT (kg) ORDER No.
BUSBAR SYSTEMS BHAIS 20673 BUSBAR HOLDER SUPPORT FOR HORIZONTAL Cu BUSBAR HOLDER UNDRILLED
DESCRIPTION
TYPE
0.50
21502

INCL
SKINNEHOLDER PROFIL

BB HOLDER WEIGHT
TYPE DESCRIPTION ORDER No.
LENGTH (kg)
BHU 4 BUSBAR HOLDER UNDRILLED 400 0.46 21440
BHU 6 BUSBAR HOLDER UNDRILLED 600 0.62 21441
BHU 8 BUSBAR HOLDER UNDRILLED 800 0.79 21442
BHU 10 BUSBAR HOLDER UNDRILLED 1000 1.12 21443
BHU 12 BUSBAR HOLDER UNDRILLED 1200 1.96 21444

Note : For Busbar Guide please refer page no. 6:06 to 6:12
For full technical specifi cation, please refer to relevant design verifi cation on www.elsteel.com
IEC 61439-2 requirements regarding busbar clearances must be followed when installing any busbar system.
Please follow safety according to G-ETRONAX P safety data sheet (Elektro-Isola A/S)
