3/356 ABB MOTOR PROTECTION AND CONTROL

—
Connection bar for contactor

1SFC101114F0001 For contactors Type Order code Pkg Weight
(1 pce)
qty
03
kg
LP185 Connection bar for contactor
GAF185 LP185 1SFN074712R1000 2 0.300
GAF300 LP300 1SFN075112R1000 2 4 0.400
LP460
0.550
GAF460
1SFN075712R1000
1SFC101117F0001 GAF750 LP750 1SFN076112R1000 4 4 4 0.950
1.900
LP1250
1SFN076412R1000
GAF1250
LP2050
GAF1650, GAF2050
1SFN076512R1000
2.900
LP2050
Maximum continuous current with two parrallel connection strips per pole
Connexion kit (includes 4 pcs of connection strips) Ie max
2 x LP185 220 A
2 x LP300 370 A
1 x LP460 600 A
1 x LP750 800 A
1 x LP1250 900 A
1 x LP2050 1650 A
