ABB MOTOR PROTECTION AND CONTROL 3/377

—

AF116 ... AF370 4-pole contactors
Terminal marking and positioning

AF116 ... AF370 contactors - AC / DC operated 03
Standard devices without addition of auxiliary contacts

1L1 3L2 5L3 7L4
A1 A2

A1 1L1 3L2 5L3 7L4
2T1 4T2 6T3 8T4
A2 2T1 4T2 6T3 8T4
AF116 ... AF370-40-00 AF116 ... AF370-40-00

Standard devices with factory mounted auxiliary contacts

A1 1L1 3L2 5L3 7L4 13X 21X
1L1 3L2 5L3 7L4 1L1 3L2 5L3 7L4 NO NC
NO
NC
A1 A2 A1 A2 A2 2T1 4T2 6T3 8T4 14X 22X
NO 13X NO 13X 43X NO
NC 21X NC 21X 31X NC AF116 ... AF370-40-11
NC 22X NC 22X 32X NC
NO 14X NO 14X 44X NO
A1 1L1 3L2 5L3 7L4 13X 21X 31X 43X
NO NC NC NO
2T1 4T2 6T3 8T4 2T1 4T2 6T3 8T4
NO NC NC NO
A2 2T1 4T2 6T3 8T4 14X 22X 32X 44X
AF116 ... AF370-40-11 AF116 ... AF370-40-22 AF116 ... AF370-40-22
