4/82 ABB MOTOR PROTECTION AND CONTROL

—
MCRC..R 4-pole mini contactor relays for ring tongue ferrules

DC operated

MCRC..R 4-pole mini contactor relays are a high performance but space saving solution used for
control functions or for switching small loads up to 6 A.
These contactors are designed with 4 poles with various contact combinations:
2CDC211028V0019 • specific screw terminals for an easy connection with ring tongue ferrules
• control circuit: DC operated
• add-on auxiliary contact blocks for front or side mounting (up to 6 additional contacts) and
a wide range of accessories
04
MCRC040AR
• suitable for rail or wall mounting.
Rated control circuit Auxiliary Type Order code Weight
voltage contacts
Uc fitted Pkg
(1 pce)
V DC kg
12 4 0 MCRC040ARB 1SAH101994R9900 0.245
3 1 MCRC031ARB 1SAH101996R9900 0.245
2 2 MCRC022ARB 1SAH101998R9900 0.245

1.50 0.04’’
56.2 2.20’’
45 1.77’’ 31 1.22’’

48 1.89’’

MCRC..R

Main dimensions mm, inches
