2/42 ABB MOTOR PROTECTION AND CONTROL

—
Accessories with Push-in Spring terminals

MS132-K, MS132-KT
02

Three-phase busbars with Push-in Spring terminals
Three-phase busbars ensure a quick and safe connection and are therefore a cost effective
solution. Busbars with Push-in Spring terminals enable tool-free wiring and eliminate the need for
routine re-tightening. Between 2 and 5 manual motor starters with none or one lateral auxiliary
contact can be connected. There is also a terminal spacer as well as a protection cover available
for busbars with Push-in Spring technology.
Suitable for Rated Number Number Type Order code Pkg Weight
operational of Manual of lateral qty (1 pce)
current motor auxiliary
PS1-2-0-65K starters contacts
A kg
MS132-K, 65 2 0 PS1-2-0-65K 1SAM301903R1002 1 0.091
MS132-KT 65 3 0 PS1-3-0-65K 1SAM301903R1003 1 0.116
65 4 0 PS1-4-0-65K 1SAM301903R1004 1 0.140
65 5 0 PS1-5-0-65K 1SAM301903R1005 1 0.165
65 2 1 PS1-2-1-65K 1SAM301903R1012 1 0.094
65 3 1 PS1-3-1-65K 1SAM301903R1013 1 0.123
65 4 1 PS1-4-1-65K 1SAM301903R1014 1 0.151
65 4 1 PS1-5-1-65K 1SAM301903R1015 1 0.178
NOTE: For product availability, please consult your ABB local sales organization.
PS1-3-1-65K

Suitable for Description Type Order code Pkg Weight
qty (1 pce)
kg
Terminal spacers, Type E/F
MS132-K, MS132-KT UL/CSA Type E/F and IEC TS1-M3-K 1SAM301913R1001 2 0.012
TS1-M3-K Additional accessories
MS132-K, MS132-KT Protection cover for PS1-K BS1-K 1SAM301904R1001 1 0.002
busbars
Padlock + two keys SA2 GJF1101903R0002 1 0.020

BS1-K

SA2
