ABB MOTOR PROTECTION AND CONTROL 2/47

—
Accessories

MS116, MS132, MS165, MO132, MO165, MS132-T, MS132-K 02

With this solution of door coupling rotary mechanisms it is possible to operate manual motor
starters in the back of a switch cabinet from outside. The door coupling mechanism prevents
opening of the door of a switch cabinet with the manual motor starter in ON position.
The complete mechanism includes handle, shaft, driver, shaft alignment ring and shaft supporter.
Most accessories fit for 6 mm shafts with a maximum length of 180 mm. The degree of protection
2CDC241003F0011 Suitable for Description Shaft Color Type Order code Pkg Weight
for handles MSHD is IP64 (NEMA Type 1, 3R, 12).
(1 pce)
length
qty
MSHD-LB mm pce kg
Shafts
MS116, For MSHD handles. Shaft 85 OXS6X85 1SCA101647R1001 1 0.020
MS132, diameter 6 mm. Shaft extension 105 OXS6X105 1SCA108043R1001 1 0.020
MS165, for door coupling driver. 130 OXS6X130 1SCA101655R1001 1 0.030
MO132, 180 OXS6X180 1SCA101659R1001 1 0.040
MO165,
MS132-T,
2CDC241002S0011 MS132-KT
MS132-K,

MSHD-LY IP64 handles (NEMA Type 1, 3R, 12) Black MSHD-LB (1) 1SAM201920R1001 1 0.065
MS116,
Padlockable max. 3 padlocks
MS132, with bail diameter 5 … 8 mm, Yellow MSHD-LY (1) 1SAM201920R1002 1 1 0.065
door interlock in ON position
2CDC241004F0011 MO132, defeatable, for use with 6 mm Yellow MSHD-LTY (2) 1SAM201920R1012 1 0.065
MS165,
Black
1SAM201920R1011
0.065
MSHD-LTB (2)
OXS6…types up to 180 mm or
MO165,
MS132-K,
MSMN MS132-T, driver shafts MSOX.
MS132-KT
Driver
MS116, Coupling driver for use MSMN (3) 1SAM101923R0002 1 0.002
MS132, with 6 mm OXS6… types MSMNO (4) 1SAM101923R0012 1 0.002
2CDC241001F0012 MO132,
MS165,
up to 180 mm.
MO165,
MSH-AR MS132-T,
MS132-K,
MS132-KT
Shaft alignment ring
MS116, The MSH-AR supports the long MSH-AR 1SAM201920R1000 1 0.010
MS132, shafts for alignment to the
MS165, handle inlet. It makes closing
MO132, panel doors more easy. Use for
MO165, OXS6X > 105 mm.
MS132-T,
2CDC241017V0013 MS132-KT
MS132-K,
Shaft supporter
MSAH1 MS116, With the MSAH it is possible to MSAH1 1SAM201909R1021 1 0.035
MS132, support the shaft in the
MO132, extension of handle (MSHD). It is
MS132-T, mandatory for the usage of
MS132-K, shafts >130 mm.
MS132-KT
(1) Indication I-O and ON-OFF (recommended for MS116)
(2) Indication I-O and ON-OFF + Trip indication
(3) Coded - Positioning of ON indication dependent on mounting orientation of the MMS
(4) Uncoded - Positioning of ON indication independent of mounting orientation of the MMS.
