AF09(Z)B..K ... AF38(Z)B..K 3-pole contactors - with Push-in Spring terminals
Electrical durability

Electrical Durability for AC-2 or AC-4 Utilization Category
Switching cage motors: starting reverse operation and step-by-step operation. The breaking current Ic is
equal to 2.5 x I e for AC-2 and 6 x I e for AC-4, keeping in mind that I e is the motor rated operational current Ie
(Ie = motor full load current).
Ambient temperature ≤ 60 °C. Maximum electrical switching frequency: see "Technical Data".
