ABB MOTOR CONTROL AND PROTECTION FOR ROLLING STOCK APPLICATIONS 3/91

—

NF(Z)B..K contactor relays - with Push-in Spring terminals
AC operated

NF(Z)B..K contactor relays comply with the latest railway rolling stock standards and allow instal-
lation in passengers or driver cabins for trains frequently operating tunnels or undergrounds.
They are used for switching auxiliary and control circuits. These contactor relays are of the block
type design with 4 or 8 main poles:
• designed in accordance to the applicable parts of IEC 60077 and EN 50155 standard
• shocks and vibration withstand conforming to IEC 61373 (category 1, class B)
• fire and smoke safety compliance to european standard EN 45545 (H2, HL3 hazard levels)
1SBC101568V0014 control voltage must not be exceeded during voltage fluctuation defined according to IEC 60077 03
• electronic coil interface accepting sinusoidal AC 50/60 Hz control supplies. Maximum permitted
or EN 50155 (see technical data)
NF(Z)B22EK • built-in surge suppression
• side by side mounting without restriction from -40 °C up to +70 °C
• add-on auxiliary contact blocks for front or side mounting and a wide range of accessories.
Number of contacts Rated control circuit Type Order code Weight
voltage
Uc min. … Uc max. Pkg
(1 pce)
V AC 50/60 Hz kg
4-pole contactor relays
A1 13 21 31 43 24...60 NFZB22EK-21 1SBH136063R2122 0.315
NO NC NC NO
48...130 NFZB22EK-22 1SBH136063R2222 0.315
NO NC NC NO 100...250 NFZB22EK-23 1SBH136063R2322 0.315
A2 14 22 32 44 250...500 NFB22EK-14 1SBH137063R1422 0.325
1SBC101570V0014 A1 A2 NO 13 14 NC 21 22 NO 33 34 NO NO 43 44 24...60 NFZB31EK-21 1SBH136063R2131 0.315
1SBH136063R2231
NFZB31EK-22
0.315
48...130
0.315
1SBH136063R2331
NFZB31EK-23
100...250
NO
NC
NO
1SBH136063R2140
0.315
NFZB40EK-21
24...60
A1 NO 13 NO 23 NO 33 NO 43 250...500 NFB31EK-14 1SBH137063R1431 0.325
NF(Z)B44EK 48...130 NFZB40EK-22 1SBH136063R2240 0.315
NO NO NO NO 100...250 NFZB40EK-23 1SBH136063R2340 0.315
A2 14 24 34 44
250...500 NFB40EK-14 1SBH137063R1440 0.325
8-pole contactor relays
A1 13 23 33 43 51 61 71 81 24...60 NFZB44EK-21 1SBH136063R2144 0.360
NO NO NO NO NC NC NC NC
48...130 NFZB44EK-22 1SBH136063R2244 0.360
NO NO NO NO NC NC NC NC 100...250 NFZB44EK-23 1SBH136063R2344 0.360
A2 14 24 34 44 52 62 72 82
250...500 NFB44EK-14 1SBH137063R1444 0.370
A1 13 23 33 43 53 61 71 83 24...60 NFZB62EK-21 1SBH136063R2162 0.360
NO NO NO NO NO NC NC NO
48...130 NFZB62EK-22 1SBH136063R2262 0.360
NO NO NO NO NO NC NC NO 100...250 NFZB62EK-23 1SBH136063R2362 0.360
A2 14 24 34 44 54 62 72 84
250...500 NFB62EK-14 1SBH137063R1462 0.370
A1 13 23 33 43 53 63 73 83 24...60 NFZB80EK-21 1SBH136063R2180 0.360
NO NO NO NO NO NO NO NO
48...130 NFZB80EK-22 1SBH136063R2280 0.360
NO NO NO NO NO NO NO NO 100...250 NFZB80EK-23 1SBH136063R2380 0.360
A2 14 24 34 44 54 64 74 84
250...500 NFB80EK-14 1SBH137063R1480 0.370
77 3.03" 110.5 4.35"
71 2.80" 71 2.79"
45 1.77" 5.5 0.22" 45 1.77" 5.5 0.22"
10.5 0.41" 10.5 0.41"
82 3.22" 35mm EN/EC 60715 5.5 0.22" 82 3.22" 35mm EN/EC 60715 5.5 0.22" 45 1.77"

10 0.39"
10 0.39"
NF(Z)B22EK, NF(Z)B31EK, NF(Z)B40EK NF(Z)B44EK, NF(Z)B62EK, NF(Z)B80EK
1SBC100616S0201
Main dimensions mm, inches
