Auxiliary contact blocks with Push-in Spring terminals

The auxiliary contact blocks are used for the operation of auxiliary circuits and control circuits for
1SBC100080V0014 standard industrial environments.
Types of auxiliary contact blocks for front mounting:
• CA4..K 1 or 4-pole block, with instantaneous N.O., N.C. contacts
Select the 4-pole auxiliary contact blocks CA4-..EK, CA4-..MK or CA4-..NK type, according to the
CA4-10K contactor or contactor relay type for compliance with the standard requirements (see "Terminal
marking and positioning").
Types of auxiliary contact blocks for side mounting:
03
1SBC100081V0014 For clipping onto the right- and/or left-hand side of the contactors.
• CAL4..K 2-pole block, with instantaneous N.O. + N.C. contacts.
The auxiliary contact blocks are equipped with push-in spring terminals protected against acci-
dental direct contact and bear the corresponding function marking.
CA4-22EK
For contactors Auxiliary Type Order code Pkg Weight
contacts qty (1 pce)

kg
Front-mounted instantaneous auxiliary contact blocks
1SBC100082V0014 AF09(Z)B..K ... AF38(Z)B..K 1 0 CA4-10K-T 1SBN010160T1010 10 0.012
4-pole NF(Z)B..K
10
1SBN010160T1001
CA4-01K-T
0 1
0.012
2 2
AF09(Z)B ... AF16(Z)B-30-10K
3 1 CA4-22MK 1SBN010146R1122 1 1 0.050
1SBN010146R1131
0.050
CA4-31MK
CAL4-11K
1 3 CA4-13MK 1SBN010146R1113 1 0.050
0 4 CA4-04MK 1SBN010146R1104 1 0.050
AF26(Z)B ... AF38(Z)B-30-00K 2 2 CA4-22EK 1SBN010146R1022 1 0.050
3 1 CA4-31EK 1SBN010146R1031 1 0.050
4 0 CA4-40EK 1SBN010146R1040 1 0.050
4-pole NF(Z)B..K 1 3 CA4-13NK 1SBN010146R1213 1 0.050
2 2 CA4-22NK 1SBN010146R1222 1 0.050
3 1 CA4-31NK 1SBN010146R1231 1 0.050
4 0 CA4-40NK 1SBN010146R1240 1 0.050
NF(Z)B40EK 0 4 CA4-04NK 1SBN010146R1204 1 0.050
Side-mounted instantaneous auxiliary contact blocks
3-pole
AF09(Z)B..K ... AF38(Z)B..K 1 1 CAL4-11K 1SBN010134R1011 1 0.030
NF(Z)B..K
Note: for each contactor or contactor relay type, refer to "Accessory fitting details" table.
