Busch-axcent®
Movement detectors / comfort switches

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Busch-Watchdog 180 flush-mounted comfort Busch-Universal relay switch insert
sensor II ) ) 3 wire connection (neutral conductor required).
2
1
with multi-lens For switching lighting systems.
For automatic switching of devices dependent on For Busch-Comfort switch control element
motion and brightness. 6815-...-101-500. For Busch-Presence detector sensor
For down-to-ground detection. 6813-…-102-500. Can be combined with Universal-Slave
For relay inserts 6401 U-102, 6402 U and 6812 U-101. insert 6440/05 U-500.
For MOS-Fet insert 6804 U-101. Operation in 1gang 2way installations via push switch-
For extension insert 6805 U. unit for combination with flush-mounted units.
With integrated selector switch for ON-AUTOMATIC-OFF Operation also possible via conventional push buttons
(lockable). (2020 US, 2021/6 UK).
Soft phase-out: In combination with the 6593 U (mode 2 supplementary inputs via 127 V push switch
of operation: Soft OFF) the illumination is dimmed (e.g. 2020 US), central disablement of all outputs
down within 60 sec and switched off. possible, supplementary IR remote control is possible
Surveillance density: 28 sectors with 112 switching via IR flying receiver 6045 E-101
segments. Rated voltage: 230 V~, +10 % / -10 %
Switch-off delay: 10 sec to 30 min or short-time pulse Rated frequency: 50 Hz - 60 Hz
1 sec adjustable. Outputs: 1x Normally open contact, potential-bound
Detection range: frontal: 15 m, lateral: 5 m, Mounting Suitable for: 230 V~ LEDi
height: 2.5 m Rated power: 100 W/VA
Detection range 2: frontal: 10 m, lateral: 2.5 m, Mounting Suitable for: 230 V incandescent lamps/230 V halogen
height: 1.2 m lamps
Detection angle: 180 ° Rated current: 10 AX
Brightness limit value: 5 Lux Up to daytime operation Rated power: 2300 W
Mounting height: 0.8 m - 1.2 m alternative: 2.5 m Suitable for: Low voltage halogen lamps operated by
Protection class (Sensor): IP 20 transformers.
Temperature range (Device): 0 °C to 35 °C Rated power: 2300 VA 11
Temperature range (Device): -5 °C to 45 °C
anthracite 6800-81-104M 2CKA006800A2269 1
Dimensions: (L x W x D): 71 mm x 71 mm x 32 mm
studio white 6800-84-104M 2CKA006800A2102 1/10 Mounting depth: 31 mm
3
black matt ) 6800-885-104M 2CKA006800A2500 1 DIN EN 60669-2-1
1) installation: slide switch top. LEDi
2) Please order the respective flush-mounted insert separately.
3) Surface painted. 6440/01 U-500 2CKA006400A0085 1
Cover plate Universal e-contact insert ) 1
Proximity switch 2-wire connection (neutral conductor not required)
For proximity switch 6406 U. For switching lighting systems. For Busch-Comfort
switch control element 6815-...-101-500.
For Busch-Presence detector sensor 6813-…-102-500.
Can be combined with Universal-Slave insert
6440/05 U-500.
anthracite 6476-81 2CKA006470A0007 1/10 Operation in 1gang 2way installations via push switch-
studio white 6476-84 2CKA006470A0004 10 unit for combination with flush-mounted units.
Operation also possible via conventional push buttons
black matt ) 6476-885 2CKA006470A0011 10 (2020 US, 2021/6 UK).
1
1) Surface painted. 2 supplementary inputs via 127 V push switch
(e.g. 2020 US), central disablement of all outputs
possible, supplementary IR remote control is possible
via IR flying receiver 6045 E-101
Rated voltage: 230 V~, +10 % / -10 %
Rated frequency: 50 Hz - 60 Hz
Outputs: 1x Normally open contact, potential-bound
Suitable for: 230 V~ LEDi
Rated power: 2 - 80 W/VA
Suitable for: 230 V incandescent lamps/230 V halogen
lamps
Rated power: 20 - 180 W
Suitable for: Low voltage halogen lamps operated by
transformers.
Rated power: 20 - 180 VA
Temperature range (Device): -5 °C to 45 °C
Dimensions: (L x W x D): 71 mm x 71 mm x 32 mm
Mounting depth: 31 mm
DIN EN 60669-2-1

6440/04 U-500 2CKA006400A0088 1
1) Only use dimmable high voltage LEDs.
