Busch-axcent®
Blind control / timers

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Control element Cover plate
For Busch-Blind control II insert 6411 U-101, with rotary knob, with marking
6411 U/S-101. For Busch-Timer insert 1070 U.
For basic blind insert 6418 U. Running time: 15 min
For Busch-Universal 2gang 1way insert 6402 U. Protection class (Device): IP 20

anthracite 6430-81-102 2CKA006430A0326 1/10 anthracite 1770-81-103 2CKA001753A0255 10
studio white 6430-84-102-500 2CKA006430A0400 1/10 studio white 1770-84-103 2CKA001753A0258 10
black matt ) 6430-885-102 2CKA006430A0386 1/10 black matt ) 1 1770-885-103 2CKA001753A0261 10
1
1) Surface painted. 1) Surface painted.

Cover plate ) 1 Cover plate
with rotary knob with rotary knob, with marking
For comfort blinds insert 6419 U. For Busch-Timer insert 1071 U.
Running time: 120 min
Protection class (Device): IP 20

anthracite 6436-81 2CKA006430A0387 10 anthracite 1771-81-103 2CKA001753A0265 10
studio white 6436-84 2CKA006430A0358 10 studio white 1771-84-103 2CKA001753A0301 10
black matt ) 6436-885 2CKA006430A0364 10 black matt ) 1 1771-885-103 2CKA001753A0304 10
2
1) Continuous lighting of the turn knob possible using glow lamp 3855. Not included 1) Surface painted.
in delivery. Neutral wire required for operation with neon lamp.
2) Surface painted. 11

Cover plate
For comfort timer control element 6455-101-500.
For standard timer control element 6456-101.
For room thermostats 1098 U-101 and 1098 UF-101.
For short-time timer 6465 U-101.
For Busch-CO2 sensor 1091 U-500.
anthracite 6436-81 2CKA006430A0387 10
studio white 6435-84 2CKA006430A0306 10
black matt ) 6435-885 2CKA006430A0389 10
1
1) Surface painted.

Time switch mechanism 16 A ) )
1
2
DP, break contact for staircases, exterior lighting, fans,
etc.
Running time: 15 min. For time-programmed switching
of electrical consumers.
Rated voltage: 230 V~, +10 % / -10 %
Rated current: 16 A, cos φ 0.25
Protection class (Device): IP 20
1070 U 2CKA001043A0025 1/10
1) For screw-fixing only
2) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
or 3060 wallbox concrete)

Time switch mechanism 16 A ) )
2
1
DP, break contact for staircases, exterior lighting, fans,
etc.
Running time: 120 min. For time-programmed switching
of electrical consumers.
Rated voltage: 230 V~, +10 % / -10 %
Rated current: 16 A, cos φ 0.25
Protection class (Device): IP 20
1071 U 2CKA001043A0124 1
1) For screw-fixing only
2) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
or 3060 wallbox concrete)
