11/192 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
Busch-axcent®
Socket outlets

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

1
SCHUKO® socket outlet SCHUKO® USB socket outlet ) ) )
3
2
With screwless terminals. shuttered
DP (2 P + E) With screwless terminals.
Rated voltage: 250 V~ DP (2 P + E)
Rated current: 16 A For supply and support of mobile devices via USB-cable.
Protection class (Device): IP 20 With USB female connector type A.
With electronic short-circuit protection.
anthracite 20 EUC-81 2CKA002011A3801 10/100 With electronic overload protection.
studio white 20 EUC-84-500 2CKA002011A6207 10/100 Simultaneous charging via USB connection and use of
the SCHUKO® socket outlet.
black matt ) 20 EUC-885 2CKA002011A3883 10/100
1
Rated voltage: 250 V~
1) Surface painted.
Secondary: 5 V-, +5 % / -5 %
Rated frequency: 50 Hz
Suitable for: SCHUKO® socket outlet
1
SCHUKO® socket outlet without claw )
shuttered Rated current: 16 A
Without claws. Suitable for: USB connection
With screwless terminals. Rated current: 700 mA
DP (2 P + E) Protection class (Device): IP 20, SELV
Rated voltage: 250 V~ Temperature range (Device): 5 °C to 35 °C
Rated current: 16 A Dimensions: (L x W x D): 71 mm x 71 mm x 53 mm
Protection class (Device): IP 20 Mounting depth: 35 mm
anthracite 20 EUCBUSB-81 2CKA002011A6158 1
anthracite 20 EUCRB-81 2CKA002013A5437 10/100
studio white 20 EUCBUSB-84-500 2CKA002011A6179 1/10
studio white 20 EUCRB-84-500 2CKA002013A5441 10/100
4
black matt ) 20 EUCRB-885 2CKA002013A5444 10/100 black matt ) 20 EUCBUSB-885 2CKA002011A6165 1
2
1) Connecting terminals approved in accordance with VDE 0620-1 as connectors.
1) Increased shock protection .
11
2) No data transfer.
2) Surface painted.
3) Use dust cover 2098 when cleaning the device.
4) Surface painted.
SCHUKO® socket outlet ) )
1
2
shuttered Busch-Socket outlet ) 1
With screw-type terminals. shuttered
DP (2 P + E) With screwless terminals.
Rated voltage: 250 V~ DP (2 P + E)
Rated current: 16 A With eject mechanism.
Protection class (Device): IP 20 Rated voltage: 250 V~
anthracite 2300 EUCB-81 2CKA002013A5448 10 Rated current: 16 A
studio white 2300 EUCB-84 2CKA002013A5451 10/100 Protection class (Device): IP 20
anthracite 20 EUCBDR-81 2CKA002013A5415 10
black matt ) 2300 EUCB-885 2CKA002013A5454 10/100
3
studio white 20 EUCBDR-84 2CKA002013A5418 10
1) Increased shock protection .
black matt ) 20 EUCBDR-885 2CKA002013A5421 10
2) With screw-type terminals 2
3) Surface painted.
1) Increased shock protection .
2) Surface painted.
SCHUKO® socket outlet )
1
shuttered 1 2
With screwless terminals. SCHUKO® socket outlet steplight® ) )
DP (2 P + E) With night orientation light
Rated voltage: 250 V~ with separate connection cables for switch contact.
Rated current: 16 A with LED,
Protection class (Device): IP 20 Shuttered.
DP (2 P + E)
anthracite 20 EUCKS-81 2CKA002013A5265 10 Rated voltage: 250 V~
studio white 20 EUCKS-84-500 2CKA002013A5372 10/100 Rated current: 16 A
Protection class (Device): IP 20
black matt ) 20 EUCKS-885 2CKA002013A5333 10/100
2
anthracite 20 EUCBLI-81 2CKA002013A5459 1
1) Increased shock protection .
2) Surface painted. studio white 20 EUCBLI-84 2CKA002013A5294 1
black matt ) 3 20 EUCBLI-885 2CKA002013A5331 1
1) Connecting terminals approved in accordance with VDE 0620-1 as connectors.
2) Resistant to aggressive media, e.g. ammonia, benzine, oils, greases, alcohol,
cleansing agents, in normal concentrations.
3) Surface painted.
