11/200 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
Busch-axcent®
Data communication

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Built-in jack Cover plate )
1
For potential balancing jack cover plate and installation 2gang
in cover plates. As cover for universal data connection boxes.
For devices of 19 mm diameter. Art. No. 0214, 0215 (Cat 3), 0220/12-507, 0221/12-507,
Protection class (Device): IP 20 0218, 0217 (Cat 5e/6 data technology) and comparable
types of the company Rutenbeck.
Brand-Rex (WAEGV 8/8 EKR/EK).
0471-0-0037 2CKA000471A0037 10 AMP (NETCONNECT 5E).
BTR (E-DAT C6, E-DAT design, Universal data connecting
unit design and IAE design).
Potential balancing plug
Suitable for plug 2095 UC-212 and built-in jack 0471-0- cti (cti-wire 2.8 Cat.6).
0037 acc. to German Standard DIN 42801. Telegärtner (AMJ 45, UMJ 45).
For potential balancing jack cover plate (connection up With down-leading outlet.
to 6 mm² crimped or soldered) With labelling field.
Protection class (Device): IP 20 Size of labelling field: 60 x 9 mm.
Protection class (Device): IP 20
0299-0-0032 2CKA000299A0032 10 anthracite 1803-02-81 2CKA001710A3615 10
studio white 1803-02-84-500 2CKA001710A1551 10/100
Blank plate black matt ) 2 1803-02-885 2CKA001710A3911 10
with metal mounting plate
Protection class (Device): IP 20 1) For compatible lettering software, visit www.BUSCH-JAEGER-labelingtool.com.
2) Surface painted.
Cover plate
For telephone connection unit.
anthracite 1742-81 2CKA001710A3612 10
For USB, VGA, HDMI inserts and communication
11
studio white 1742-84-500 2CKA001710A3991 10/100 adapter.
1
black matt ) 1742-885 2CKA001710A3895 10 USB power adapter insert 6472 U.
For loudspeaker connection box.
1) Surface painted.
Suitable for part number 0248/0x-101.
For data modules.
Cover plate ) 1 Suitable for Art. No. 0219/12 and 0219/13.
with flex outlet For modular outlets with 90° RJ45 outlet from
As cover for flex outlet, for cords up to 10.3 mm Telegärtner (type MJ and WE).
diameter. Protection class (Device): IP 20
With strain relief (without terminal block). anthracite 1766-81 2CKA001710A3613 10
Protection class (Device): IP 20
studio white 1766-84-500 2CKA001710A3992 10/100
anthracite 1749-81 2CKA001710A3614 10 black matt ) 1 1766-885 2CKA001710A3903 10
studio white 1749-84 2CKA001710A3163 10/100 1) Surface painted.
black matt ) 1749-885 2CKA001710A3900 10
2
1) Cover plate can also be used individually as cover for telephone connector boxes Cover plate
(VDo). As cover for telephone connector boxes (VDo).
2) Surface painted.
Can be knocked out for single or double connection.
Protection class (Device): IP 20
Cover plate ) 1
As cover for universal data connection boxes.
Art.-No. 0213 (Cat 3/ISDN), 0216-101, 0218/11-101 (Cat anthracite 1745-81 2CKA001710A3624 10
5e/6 data technology) and comparable types of the
company Rutenbeck. studio white 1745-84 2CKA001710A3173 10
For WLAN access points 8186/31 and 8186/41. black matt ) 1 1745-885 2CKA001710A3896 10
Brand-Rex (WAEGV 8 EKR/EK).
1) Surface painted.
BTR ( universal data connecting unit design and IAE
design).
Telegärtner (AMJ 45, UMJ 45). Cover plate )
1
With down-leading outlet. socket outlet
With labelling field. Telephone socket (TDO)
Size of labelling field: 60 x 9 mm.
Protection class (Device): IP 20
anthracite 1803-81 2CKA001710A3616 10
studio white 1803-84-500 2CKA001710A1550 10/100 anthracite 1762-81-506 2CKA001710A4103 10/100
black matt ) 1803-885 2CKA001710A3912 10 studio white 1762-84-506 2CKA001710A4106 10/100
2
1) For compatible lettering software, visit www.BUSCH-JAEGER-labelingtool.com. black matt ) 2 1762-885-506 2CKA001710A4109 10/100
2) Surface painted.
1) Suitable insert: TDO 3x 10 OUP (for 1 telephone and 2 auxiliary devices).
2) Surface painted.
