Busch-axcent®
Multimedia / communication adapters

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

3
2
Busch-powerDock Charging cradle with USB-C USB charging station insert ) ) )
1
connection For supply and support of mobile devices via USB-cable.
For Busch-powerDock insert 6473 U. With micro USB connecting cable. Connecting cable
For attaching mobile terminal devices with USB-C joined captive to insert. Usable cable length (incl. micro
connection. USB plug) approx. 22 cm.
Temperature range (Device): 5 °C to 35 °C With electronic short-circuit protection.
Dimensions: (L x W x D): 54 mm x 54 mm x 36 mm With electronic overload protection.
Rated voltage: 100 - 230 V~, +10 % / -10 %
6473/11-500 2CKA006400A0083 1/10
Secondary: 5 V-, +5 % / -5 %
Rated frequency: 50 Hz - 60 Hz
USB power adapter insert, flush-mounted ) ) ) ) Rated current: 1400 mA
4
3
1
2
For supply and support of mobile devices via USB-cable. Protection class (Device): IP 20, SELV
With two USB type A outputs. Temperature range (Device): 5 °C to 40 °C
To support two devices at the same time. Dimensions: (L x W x D): 71 mm x 71 mm x 35 mm
With electronic short-circuit protection. Mounting depth: 32 mm
With electronic overload protection. 6474 U-500 2CKA006400A0033 1/10
Rated voltage: 100 - 230 V~, +10 % / -10 % 1) No claw. Screw-fixing via keyholes.
Secondary: 5 V-, +5 % / -5 % 2) No data transfer.
Rated frequency: 50 Hz - 60 Hz 3) For terminal devices with standardized charging interface according to DIN EN
Suitable for: In case one output is used: 62684.
Rated current: 1400 mA
Suitable for: In case two output are used: 1
Rated current: 700 mA HDMI connection unit )
Protection class (Device): IP 20, SELV with screw-type terminals and strain relief
Temperature range (Device): 5 °C to 40 °C Suitable for telephone connection unit cover plates
Dimensions: (L x W x D): 71 mm x 71 mm x 43 mm 2539-21x and 1766-xxx. 11
Mounting depth: 32 mm To link high-definition digital audio and video data from
e.g. SAT-receiver, DVD-/Blue-Ray-player to plasma-type,
6472 U-500 2CKA006400A0002 1 LCD- or-LED-TVs/screens. HDMI-type A, 3D-compatible.
1) No claw. Screw-fixing via keyholes. Fully HD ready (1920 x 1080 pixel).
2) No data transfer. For 20-wire HDMI-cables via srew-type terminals.
3) For terminal devices with standardized charging interface according to DIN EN For trunk systems, flush-mounted wall boxes and
62684. underfloor systems.
4) Use dust cover 2098 when cleaning the device.
For easy installation and to follow the valid bending
radii the "Kaiser- electronic-wall-box" type 1068-02 or
USB power adapter insert, flush-mounted ) ) ) ) 9062-74 is recommended.
3
2
1
4
For supply and support of mobile devices via USB-cable. Without cover plate. Without claws.
With two USB type A outputs. Protection class (Device): IP 20
To support two devices at the same time. Mounting depth: 34 mm
With electronic short-circuit protection. white 0261/31-500 2CKA000230A0430 1
With electronic overload protection.
Rated voltage: 120 - 230 V~, +10 % / -10 % grey 0261/33-500 2CKA000230A0432 1
Secondary: 5 V-, +5 % / -5 % alpine white 0261/32-500 2CKA000230A0431 1
Rated frequency: 50 Hz / 60 Hz 1) Please follow the recommendations of the cable and device producers for the max.
Suitable for: In case one output is used: HDMI cable lengths.
Rated current: 3 A
Suitable for: In case two output are used:
Rated current: 1.500 mA VGA connection unit )
1
Protection class (Device): IP 20, SELV with screw-type terminals and strain relief
Temperature range (Device): 0 °C to 35 °C Suitable for telephone connection unit cover plates
Dimensions: (L x W x D): 71 mm x 71 mm x 43 mm 2539-21x and 1766-xxx.
Mounting depth: 32 mm To link analogue video data between PCs and laptops
to monitors or digital projectors etc. VGA-type: D-type,
Available from November 2019 15-pole. Fully HD ready (1920 x 1080 pixel).
For 15-wire VGA-cables via srew-type terminals.
6472 U-500-101 2CKA006400A0094 1
For trunk systems, flush-mounted wall boxes and
1) No claw. Screw-fixing via keyholes.
underfloor systems.
2) No data transfer.
For easy installation and to follow the valid bending
3) For terminal devices with standardized charging interface according to DIN EN
radii the "Kaiser- electronic-wall-box" type 1068-02 or
62684.
4) Use dust cover 2098 when cleaning the device. 9062-74 is recommended. Without cover plate.
Without claws.
Protection class (Device): IP 20
Mounting depth: 34 mm
white 0261/21-500 2CKA000230A0424 1
grey 0261/23-500 2CKA000230A0426 1
alpine white 0261/22-500 2CKA000230A0425 1
1) Please follow the recommendations of the cable and device producers for the max.
VGA cable lengths.
