future® linear
Rocker switches / push switches

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Switch rocker with marking Switch rocker with marking
With bell symbol. with small transparent lens
For flush-mounted push switch. With bell symbol.
Protection class (Device): IP 20 For flush-mounted push switch.
Protection class (Device): IP 20

anthracite 2520 KI-81 2CKA001751A3176 10/100 anthracite 1789 KI-81 2CKA001751A2932 10
ivory white 2520 KI-82 2CKA001751A3177 10/100 ivory white 1789 KI-82 2CKA001751A2746 10
aluminium 2520 KI-83 2CKA001751A3178 10/100 aluminium 1789 KI-83 2CKA001751A2952 10
silver ) silver ) 1
1
studio white 2520 KI-84-500 2CKA001751A3180 10/100 studio white 1789 KI-84 2CKA001751A2754 10
studio white, 2520 KI-884 2CKA001751A3182 10/100 studio white, 1789 KI-884 2CKA001751A3030 10
matt ) matt ) 1
1
black matt ) 2520 KI-885 2CKA001751A3183 10/100 black matt ) 1 1789 KI-885 2CKA001751A3044 10
1
1) Surface painted. 1) Surface painted.
Switch rocker with marking Rocker ) )
1
2
with small transparent lens with labelling field
With symbol. With bell symbol.
As cover for flush-mounted 1gang 1way, 1gang 2way With pilot lamp for uniform illumination of the labelling
switch, intermediate switch, push-button and control field.
switch 1gang 2way. For flush-mounted push switch.
Protection class (Device): IP 20 Size of labelling field: 59.7 x 11.7 mm. 11
Protection class (Device): IP 20
anthracite 1789 LI-81 2CKA001751A2931 10
ivory white 1789 LI-82 2CKA001751A2745 10 anthracite 1764 NLI/KI-81 2CKA001731A3998 10/100
ivory white 1764 NLI/KI-82 2CKA001731A3999 10/100
aluminium 1789 LI-83 2CKA001751A2951 10
silver ) aluminium 1764 NLI/KI-83 2CKA001731A4000 10/100
1
studio white 1789 LI-84-500 2CKA001751A3084 10/100 silver ) 3
studio white, 1789 LI-884 2CKA001751A3031 10 studio white 1764 NLI/KI-84-500 2CKA001731A4002 10/100
1
matt ) studio white, 1764 NLI/KI-884 2CKA001731A4004 10/100
black matt ) 1789 LI-885 2CKA001751A3045 10 matt ) 3
1
black matt ) 3 1764 NLI/KI-885 2CKA001731A4005 10/100
1) Surface painted.
1) For compatible lettering software, visit www.BUSCH-JAEGER-labelingtool.com.
2) Illumination using neon lamp 8353 or incandescent lamp 8344-1 and LED inserts.
Switch rocker with marking 3) Surface painted.
with small transparent lens
With key symbol.
2
1
For flush-mounted push switch. Rocker ) )
Protection class (Device): IP 20 with labelling field
With pilot lamp for uniform illumination of the labelling
field.
anthracite 1789 TR-81 2CKA001751A2933 10 For flush-mounted switch 1g1w, 1g2w, intermediate,
ivory white 1789 TR-82 2CKA001751A2747 10 push switch.
Size of labelling field: 59.7 x 11.7 mm.
aluminium 1789 TR-83 2CKA001751A2953 10 Protection class (Device): IP 20
1
silver )
anthracite 1764 NLI-81 2CKA001731A1552 10
studio white 1789 TR-84 2CKA001751A2755 10
ivory white 1764 NLI-82 2CKA001731A1876 10
studio white, 1789 TR-884 2CKA001751A3032 10
1
matt ) aluminium 1764 NLI-83 2CKA001731A1948 10
silver ) 3
1
black matt ) 1789 TR-885 2CKA001751A3046 10
studio white 1764 NLI-84 2CKA001731A1877 10/100
1) Surface painted.
studio white, 1764 NLI-884 2CKA001731A1985 10
matt ) 3
black matt ) 3 1764 NLI-885 2CKA001731A1982 10
red RAL 3020 1764 NLI-12-82-101 2CKA001731A4011 10
Green, RAL 1764 NLI-13-82 2CKA001731A4007 10/100
6032
1) For compatible lettering software, visit www.BUSCH-JAEGER-labelingtool.com.
2) Illumination using neon lamp 8353 or incandescent lamp 8344-1 and LED inserts.
3) Surface painted.
