11/224 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
future® linear
Rocker switches / push switches

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Switch rocker with marking Switch rocker with marking
with small red spherical cap For flush-mounted switch 1g1w, 1g2w, intermediate,
With imprint "0" and "I". push switch.
As cover for 2-pole or 3-pole flush-mounted on-off DO NOT DISTURB
switch and 2-pole control on-off switch. Protection class (Device): IP 20
Protection class (Device): IP 20
anthracite 1788-81 2CKA001751A2927 10 anthracite 1786/11-81 2CKA001751A3207 10
ivory white 1788-82 2CKA001751A2742 10 ivory white 1786/11-82 2CKA001751A2997 10
aluminium 1788-83 2CKA001751A2954 10 aluminium 1786/11-83 2CKA001751A3001 10
silver ) silver ) 1
1
studio white 1788-84 2CKA001751A2750 10/100 studio white 1786/11-84 2CKA001751A2998 10
studio white, 1788-884 2CKA001751A3028 10 studio white, 1786/11-884 2CKA001751A3026 10
matt ) matt ) 1
1
black matt ) 1788-885 2CKA001751A3042 10 black matt ) 1 1786/11-885 2CKA001751A3040 10
1
1) Surface painted. 1) Surface painted.
Switch rocker with marking Switch rocker with marking
with small red spherical cap For flush-mounted switch 2g 1w, 2g push switch.
With marking "Heizung". DO NOT DISTURB
As cover for flush-mounted 1gang 1way, 1gang 2way MAKE UP ROOM
switch, intermediate switch, push-button and control Protection class (Device): IP 20
switch 1gang 2way.
As cover for 2-pole or 3-pole flush-mounted on-off
11
switch and 2-pole control on-off switch. anthracite 1785/11-81 2CKA001751A3205 10
Protection class (Device): IP 20 ivory white 1785/11-82 2CKA001751A2991 10
anthracite 1789 H-81 2CKA001751A2929 10 aluminium 1785/11-83 2CKA001751A2995 10
ivory white 1789 H-82 2CKA001751A2743 10 silver ) 1
aluminium 1789 H-83 2CKA001751A2955 10 studio white 1785/11-84 2CKA001751A2992 10
silver ) studio white, 1785/11-884 2CKA001751A3023 10
1
studio white 1789 H-84 2CKA001751A2751 10 matt ) 1
studio white, 1789 H-884 2CKA001751A3029 10 black matt ) 1 1785/11-885 2CKA001751A3037 10
1
matt ) 1) Surface painted.
black matt ) 1789 H-885 2CKA001751A3043 10
1
1) Surface painted. Bell push-switch DND/MUR
with marking "Do not Disturb" and "Make up Room"
two seperate LED indicators
Card switch 10 A ) with screw-type terminal
1
SP, with normally open contact (operating current) Rated voltage: 250 V~
Illuminable. Rated current: 10 ABS EN 60669-1, IEC 60669-1
With N terminal.
Rated voltage: 250 V~ anthracite 2029 UC-81 2CKA001751A3167 1
Rated current: 10 A ivory 2029 UC-82 2CKA001751A3168 1
Protection class (Device): IP 20IEC60669-1, British
Standard EN 60669-1 aluminium 2029 UC-83 2CKA001751A3169 1
silver ) 1
2025 U 2CKA001012A1713 10
studio white 2029 UC-84 2CKA001751A3170 1
Mounting 35 mm deep flush 1gang
boxes: or Dual Box 3070-2/35 BSDB. studio white, 2029 UC-884 2CKA001751A3172 1
matt ) 1
2gang product 2gang combination with adapter plate
combinations: APBS in Dual Box only. black matt ) 1 2029 UC-885 2CKA001751A3173 1
1) Surface painted.
delivery form: Adapter plate APBS to be ordered separate.
1) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
or 3060 wallbox concrete)
