11/252 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
future® linear
Data communication

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Built-in jack Cover plate )
1
For potential balancing jack cover plate and installation As cover for universal data connection boxes.
in cover plates. Art.-No. 0213 (Cat 3/ISDN), 0216-101, 0218/11-101 (Cat
For devices of 19 mm diameter. 5e/6 data technology) and comparable types of the
Protection class (Device): IP 20 company Rutenbeck.
For WLAN access points 8186/31 and 8186/41.
Brand-Rex (WAEGV 8 EKR/EK).
0471-0-0037 2CKA000471A0037 10 BTR ( universal data connecting unit design and IAE
design).
Telegärtner (AMJ 45, UMJ 45).
Potential balancing plug
Suitable for plug 2095 UC-212 and built-in jack 0471-0- With down-leading outlet.
0037 acc. to German Standard DIN 42801. With labelling field.
For potential balancing jack cover plate (connection up Size of labelling field: 60 x 9 mm.
to 6 mm² crimped or soldered) Protection class (Device): IP 20
Protection class (Device): IP 20 anthracite 1803-81 2CKA001710A3616 10
0299-0-0032 2CKA000299A0032 10 ivory white 1803-82 2CKA001710A3147 10
aluminium 1803-83 2CKA001710A3674 10
silver ) 2
Blank plate
with metal mounting plate studio white 1803-84-500 2CKA001710A1550 10/100
Protection class (Device): IP 20 studio white, 1803-884 2CKA001710A3889 10
matt ) 2
black matt ) 2 1803-885 2CKA001710A3912 10
1) For compatible lettering software, visit www.BUSCH-JAEGER-labelingtool.com.
anthracite 1742-81 2CKA001710A3612 10 2) Surface painted.
11
ivory white 1742-82 2CKA001710A3143 10
1
aluminium 1742-83 2CKA001710A3664 10 Cover plate )
silver ) 2gang
1
As cover for universal data connection boxes.
studio white 1742-84 2CKA001710A3161 10/100
Art. No. 0214, 0215 (Cat 3), 0220/12-507, 0221/12-507,
studio white 1742-84-500 2CKA001710A3991 10/100 0218, 0217 (Cat 5e/6 data technology) and comparable
studio white, 1742-884 2CKA001710A3873 10/100 types of the company Rutenbeck.
1
matt ) Brand-Rex (WAEGV 8/8 EKR/EK).
AMP (NETCONNECT 5E).
black matt ) 1742-885 2CKA001710A3895 10 BTR (E-DAT C6, E-DAT design, Universal data connecting
1
1) Surface painted. unit design and IAE design).
cti (cti-wire 2.8 Cat.6).
Telegärtner (AMJ 45, UMJ 45).
Cover plate ) 1 With down-leading outlet.
with flex outlet With labelling field.
As cover for flex outlet, for cords up to 10.3 mm Size of labelling field: 60 x 9 mm.
diameter. Protection class (Device): IP 20
With strain relief (without terminal block).
Protection class (Device): IP 20 anthracite 1803-02-81 2CKA001710A3615 10
ivory white 1803-02-82 2CKA001710A3146 10
anthracite 1749-81 2CKA001710A3614 10
aluminium 1803-02-83 2CKA001710A3610 10/100
ivory white 1749-82 2CKA001710A3145 10
silver ) 2
aluminium 1749-83 2CKA001710A3665 10 studio white 1803-02-84-500 2CKA001710A1551 10/100
silver )
2
studio white, 1803-02-884 2CKA001710A3888 10
studio white 1749-84 2CKA001710A3163 10/100
matt ) 2
studio white, 1749-884 2CKA001710A3878 10 black matt ) 2 1803-02-885 2CKA001710A3911 10
matt )
2
1) For compatible lettering software, visit www.BUSCH-JAEGER-labelingtool.com.
black matt ) 1749-885 2CKA001710A3900 10 2) Surface painted.
2
1) Cover plate can also be used individually as cover for telephone connector boxes
(VDo).
2) Surface painted.
