11/256 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
future® linear
Data communication Multimedia / communication adapters

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

2
1
Cover plate ) 1 Busch-DigitalRadio ) ) ) ) )
5
4
3
with metal mounting plate RDS stereo radio alarm clock for flush-mounted
for communication devices. installation.
With labelling field 60.2 x 10.2 mm. Reception frequency: 87.50 MHz - 108.00 MHz.
Without claws. With display and background illumination.
Protection class (Device): IP 20 With external AUX input.
For mono/stereo operation.
anthracite 1758-81 2CKA001724A4253 10 8 radio stations storable.
ivory white 1758-82 2CKA001724A2759 10 With time display.
With alarm function.
aluminium 1758-83 2CKA001724A4263 10
silver ) With automatic switch-off function (automatic sleep
2
mode).
studio white 1758-84 2CKA001724A2761 10/100 With extension input to remote-controlled ON/OFF
studio white, 1758-884 2CKA001724A4307 10 switches.
matt ) With integrated antenna.
2
With additional connection for external antenna.
black matt ) 1758-885 2CKA001724A4299 10
2
Permitted speaker impedance: 4 - 8 Ohm
1) For compatible lettering software, visit www.BUSCH-JAEGER-labelingtool.com. Can be installed as 1gang and in multiple combinations.
2) Surface painted.
Rated voltage: 230 V~, +10 % / -10 %
Rated frequency: 50 Hz - 60 Hz
Protection class (Device): IP 20
Intermediate ring
For attaching cover plates with the dimensions of 55 x Temperature range (Device): 5 °C to 40 °C
55 mm. Dimensions: (L x W x D): 71 mm x 71 mm x 49 mm
Protection class (Device): IP 20 Mounting depth: 34 mm
8215 U-500 2CKA008200A0182 1/10
1) No claw. Screw-fixing via keyholes.
11
2) Matching loudspeaker insert 8223 U.
ivory white 1747-82 2CKA001710A3860 10 3) Also combinable with built-in ceiling loudspeaker (8225 EB & 8226 EB) and HiFi
aluminium 1747-83 2CKA001710A4090 10 built-in ceiling loudspeaker (8226/11 EB).
silver ) 4) Can also be combined with built-in loudspeaker (8222 EB) and moist atmosphere
1
loudspeaker (8224 EB).
studio white 1747-84 2CKA001710A3861 10 5) To be mounted only in connection with commercially available flush-mounted
1) Surface painted. installation boxes according to DIN 49073 > 40 mm depth gauge or Busch-Jaeger
art. no. 3040, 3050 or 3060.
