11/618 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
Concept bs
Dimmers Function control switches

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Touch-type dimmer with IR Volume control switch
Power: 700W/VA 5-15W, (0-100)V~
Lighting: With fire alarm terminal
Manual/remote control
Control current max. 50mA DC

Cover White AC416 8
White 6066-84 1 Silver AC416-S 8
Silver 6066-83 1
Insert Volume control switch
6550 U-101-500 1 Max.5W, (0-100)V~
With fire alarm terminal
Adapter plate Low resistance, average 8 Ohm
White AC503 20
Silver AC503-S 20
White AC416-001 8
Touch dimmer LED Silver AC416-S01 8
Power: 2W/VA-700W/VA
Lighting: , Countdown timer & 1-gang 1-way combination switch
For incandescent lamps,230V tungsten halogen lamps 10AX, 250V~
and low-voltage Time setting: 10-120min
Two seperate switching contacts
Cover
11
White 6066-84 1
White AC411 10
Silver 6066-83 1
Silver AC411-S 10
Insert
6524 U-500 1
Emergency switch
Adapter plate
6A, 230V~
White AC503 20 Sending alarm signal manually, using key to release
Silver AC503-S 20
Incandescent and 230V halogen lamps White AC419 10
Low voltage halogen lamps with conventional transformer.
In the case of conventional transformers, take Silver AC419-S 10
~20% transformer loss into account.
Low voltage halogen lamps with electronic transformer.
In case of electronic transformers, 5% transformer losses.
Fluorescent lamps with electronic ballasts
