ABB i-bus® KNX
System Infrastructure and Interfacing

Magnetic Contact EnOcean
The Magnetic Contact EnOcean is a surface mounted device for windows or doors recogniz-
ing opening or closing. The magnetic contact EnOcean communicates on this with a gateway
via radio.
The frequency is 868.3 MHz. The interior range is up to 30 m, typically 5 – 10 m, depending on
the structural conditions. When using the ABB i-bus® KNX/EnOcean Gateway EG/A 32.2.1,
to link to the KNX-Bus, the signal strength can be measured with the ABB i-bus® Tool.
MKE/A 1.868.1 The magnetic contact supplies itself with power via a solar cell and does not require a bat-
tery or other supply voltage.

Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit
Type code Order code kg pc.
– MKE/A 1.868.1 2CDG120048R0011 0.1 1

KNX TP/RF WaveLine Gateway, SM
Media converter with internal antenna for conversion of KNX RF WaveLine radio signals to
KNX twisted pair networks with 24 channels. For the evaluation and transfer of up to
24 channels each with 4 sub-channels as transmitter or receiver. Simple operation due to
“programming button” and display on the device. Is surface-mounted. The KNX/WaveLine
Gateway is powered via KNX and does not require an additional power supply.
6770-500
Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit

Type code Order code kg pc.
– 6770-500 2CKA006770A0002 0.15 1
WaveLINE components are available in chapter WaveLINE wireless control.
