14/150 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
ABB i-bus® KNX
Guest Room Management

Set of Transponder Cards for Millenium,
Chiara 2 modules and Tacteo design programs
The transponder card uses passive transponder technology operating in radio frequency
(MIFARE technology), without the need for contact between the reader and the card itself.
The transponder card is read by swiping it in front of the reader at a maximum distance
TS/T 1
TS/T 1.1 of 20 mm (can be reduced according to installation environment).

Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit
Type code Order code kg pc.
10 transponder cards – TS/T 1 2CSY259412R2041 0.02 1
1000 transponder cards – TS/T 1.1 2CSY232175R2041 1 1

Transponder Reader, Mylos
The transponder reader is used for access control in the hotel, residential and commercial
sectors (office buildings, business centers, laboratories, etc.). The device is equipped
with two bistable relays (8 A, 250 V AC), one of which can be assigned to control electronic
lock, and three voltage-free, non-optically insulated inputs; the 5-V DC scanning voltage is
available on the COM terminal.
The transponder reader requires a 10...32 V DC/12...24 V AC external power supply to ensure
its operation even with bus voltage failure.

Description Mod. Order details Price Weight Pack
LT/U 1.1.MC width 1 piece 1 piece unit
LT/U 1.1.MS
Type code Order code kg pc.
white – LT/U 1.1.MC 2CSYK5000C 0.05 1
black – LT/U 1.1.MS 2CSYK5000S 0.05 1

Transponder Holder, Mylos
14
The transponder holder is equipped with a slot into which the transponder card is inserted.
In a hotel application, this allows occupancy recognition and notification at the supervisory
level (e.g. on the front desk computer).
Moreover, room status information can be managed by using special cards (minibar status,
PTI/U 1.1.MC maintenance status, usability).
The device is equipped with 2 bistable relays (8 A, 250 V AC) and 3 voltage-free, non-optically
insulated inputs; the 5-V DC scanning voltage is available on the COM terminal.
The transponder pocket requires a 10...32 V DC/12...24 V AC external power supply to ensure
its operation even with bus voltage failure.

Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit
Type code Order code kg pc.
white – PTI/U 1.1.MC 2CSYK5200C 0.05 1
black – PTI/U 1.1.MS 2CSYK5200S 0.05 1
