14/151

—
ABB i-bus® KNX
Guest Room Management

Transponder Programming Device, Mylos
The devices allows the programming of transponder cards.
The device is equipped with 2 bistable relays (8 A, 250 V AC) and 3 voltage-free non-optically
insulated inputs; 5 V DC scanning voltage is available on the COM terminal.
The transponder programmer requires a 10...32 V DC/12...24 V AC external power supply to
PRT/U 1.1.MC ensure its operation even with bus voltage failure.

Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit
Type code Order code kg pc.
white – PRT/U 1.1.MC 2CSYK5300C 0.05 1
black – PRT/U 1.1.MS 2CSYK5300S 0.05 1

Set of 5 Transponder Cards for Chiara and Mylos design programs
The transponder card uses passive transponder technology operating in radio frequency,
without the need for contact between the reader and the card itself. The transponder card is
read by swiping it in front of the reader at a maximum distance of 20 mm.
CH/T 2
CH/T 2.1 Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit

Type code Order code kg pc.
5 transponder cards – CH/T 2 2CSKK5400C 0.005 1
1000 transponder cards – CH/T 2.1 2CSY289611R1941 1 1

Transponder Reader, Chiara
The transponder reader is used for access control in the hotel, residential and commercial
sectors (office buildings, business centers, laboratories, etc.). The device is equipped
with two bistable relays (8 A, 250 V AC), one of which can be assigned to control electronic
lock, and three voltage-free, non-optically insulated inputs; the 5-V DC scanning voltage is 14
LT/U 1.1.CH available on the COM terminal.
The transponder reader requires a 10...32 V DC/12...24 V AC external power supply to ensure
its operation even with bus voltage failure.

Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit

Type code Order code kg pc.
white – LT/U 1.1.CH 2CSKK5000C 0.05 1
