          ABB i-bus® KNX
          User Operation – Design Ranges –
          Millenium


                                    Busch-Watchdog 180 flush mounted standard sensor
                                    Movement sensor with up to four channels. Detection range: frontal: 6 m, lateral: 6 m.
                                    Detection angle: 180 °. Brightness limit value: 5 Lux – 150 Lux. Mounting height: 1.1 m
                                    Protection class (Device): IP 20. Temperature range (Device): – 5 °C to 45 °C.
                                    Dimensions: (L x W x D): 53 mm x 44 mm. Position for installation: vertical.
         6122/20-981-500
                                    Description          Mod.  Order details                Price Weight  Pack
                                                         width                             1 piece 1 piece  unit
                                                              Type code     Order code           kg      pc.
                                                         –    6122/20-981-500  2CKA006132A0306   0.084   1


                                    Room Thermostat
                                    Control element with room thermostat function for triggering the heating, ventilation and
                                    fan-coil actuators. The controller is a thermostat for Fan Coil units in 2- and 4-pipe systems
                                    and conventional heating or cooling systems. The fan stage can be switched manually or in
                                    automatic mode. Incl. 10 logic channels (light scene actuator, sequence actuator, logic gates,
                                    etc.).
          6124/08-981-500
                                    Switch contacts for operating mode selection and dial for setpoint or fan speed adjustment.
                                    Display elements: LCD showing operation modes. Protection class (Device): IP 20.
                                    Temperature range (Device): – 5 °C to 45 °C. Dimensions: (L x W x D): 53 mm x 44 mm.

                                    Description          Mod.  Order details                Price Weight  Pack
                                                         width                             1 piece 1 piece  unit
                                                              Type code     Order code           kg      pc.
                                                         –    6124/08-981-500  2CKA006134A0309   0.101   1


                                    Buttons with symbols
                                    Buttons with symbols for Millenium control covers 1 / 2-gang, 2 / 4-gang, 3 / 6-gang and
                                    3 / 6-gang with infrared.                                                          14


                                    Description          Mod.  Order details                Price Weight  Pack
                                                         width                             1 piece 1 piece  unit
                                                              Type code     Order code           kg      pc.
                                    Symbol for marking “Light”  –  6123/20-500  2CKA006123A0001  0.011   1
                                    Symbol for marking “blinds” –  6123/21-500  2CKA006123A0002  0.011   1
                                    Symbol for marking “scene”  –  6123/22-500  2CKA006123A0003  0.011   1
                                    Symbol for marking   –    6123/23-500   2CKA006123A0004      0.011   1
                                    “temperature”
                                    Symbol for marking   –    6123/24-500   2CKA006123A0005      0.003   1
                                    “ceiling light”
                                    Symbol for marking   –    6123/26-500   2CKA006123A0006      0.003   1
                                    “Fan Coil”
