14/296 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
ABB i-bus® KNX
User Operation – Design Ranges –
Chiara

Binary Input, 2-fold, with Rocker Switch NEW
Device equipped with: 1 rocker switch; 2 binary input channels that can be used to interface
to KNX system conventional push-buttons/rocker switches, or auxiliary/technical contacts.
LEDs for the functional signaling of the load to which the rocker switch is connected. Flush-
mounted installation.
2CSKK1002C
Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit
Type code Order code kg pc.
white – 2CSKK1002C 2CSK206571R1002 0.12 1

Binary Input, 2-fold, with Rocker Switches, 2 gang NEW
Device equipped with: 2 rocker switches; 2 binary input channels that can be used to inter-
face to KNX system conventional push-buttons/rocker switches, or auxiliary/technical con-
tacts. LEDs for the functional signaling of the load to which the rocker switch is connected.
Flush-mounted installation.
2CSKK1003C
Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit
Type code Order code kg pc.
white – 2CSKK1003C 2CSK232195R1003 1

Thermostat NEW
Standard KNX thermostat equipped with backlight LCD display 4 push buttons on the front-
for the following functionalities (Operating mode switching, Fan-coil speed manual switch-
ing, set-point manual increment/decrement). Possibility to choose different type of control:
2-point ON/OFF, PWM, Continue, Fan- coil.

2CSKK1202C
Description Mod. Order details Price Weight Pack
14
width 1 piece 1 piece unit
Type code Order code kg pc.
white – 2CSKK1202C 2CSK232205R1202 0.07 1

Set of 4 cover DND/MUR NEW
Cover for Chiara KNX device 2CSKK1002C. With Do-Not-Disturb/Make-Up-Room symbols.

Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit
2CSKK1504C Type code Order code kg pc.
white – 2CSKK1504C 2CSK232155R1504 1

Please visit
https://new.abb.com/low-voltage/products/residential-product/switch-ranges/chiara
to see the list of all cover plates and devices that are available.
